10kw/12.5kva Single/three Phase Gasoline Generator

10kw/12.5kva Single/three Phase Gasoline Generator photo-1
10kw/12.5kva Single/three Phase Gasoline Generator photo-2
10kw/12.5kva Single/three Phase Gasoline Generator photo-3
10kw/12.5kva Single/three Phase Gasoline Generator photo-4
10kw/12.5kva Single/three Phase Gasoline Generator photo-5
US$ 1,080 - 1,190 MOQ: 10 Sets
Key Specifications
Get Latest Price
Brand Name:
ITCPower
Place of Origin:
Jiangsu, China
Model Number:
GG12000LE/GG12000LE-3
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Brand Name ITCPower
Place of Origin Jiangsu, China
Model Number GG12000LE/GG12000LE-3
Rated Current 41.7A
Speed 3000/3600RPM
Frequency 60HZ
Rated Voltage 240V
Rated Power 10kw/10kva/12.5kva

10kw/12.5kva single/three phase gasoline generator

1. Specification of our 10kw/10kva GG12000LE 60Hz single phase electric open gasoline generator



Discrebtion Generator Model GG12000LE
Reference Open frame
Diesle Generator Rated Power(kVA) 10kva
Max.Power(kVA) 11kva
Frequency (Hz) 60HZ
Voltage (V) 240
Current (A) 41.7
Sockets EU 1x16A,1x63A
Display LED4
Battery (Ah)  12V/36Ah
Fuel Tank Capacity (L) 28
Running Time under 50% Load (hr.)  6
Noise Level behind 7 Meters (dBA) 79
DC Output (V/A) 12/8.3
ATS connector Yes
ATS control box Yes
Remote Control as optional Yes
Push Wheels kit as optional Yes
Engine Engine  IC680E
Power Output (HP/3000rpm) 20
Start Mothod Electric
Displacement (cc) 678
Oil Capacity (L) 1.5
Alternator Alternator  10KVA245L~130/G50(G60)
Rated Power (kW) 10
Power Factor (Cosφ) 1
Voltage Regulation AVR / Brush type
Transportation Data N.G.kg 172
G.W.kg 195
Product Dimension (mm) 930*620*705
Package Dimension (mm) 960*650*750
Max Quantity(set)/Container 48/20GP;102/40GP;102/40HQ






  2. Why choose our 10KW 60hz single phase electric open gasoline generator ?

ITCPower Team



10kw/12.5kva  single/three phase gasoline  generator




ITCPower Factory



10kw/12.5kva  single/three phase gasoline  generator







 3. Certification of our 10kw 60hz single phase electric open gasoline generator



ITCPower generator Certificate   Show

10kw/12.5kva  single/three phase gasoline  generator







ITCPower generator Show



10kw/12.5kva  single/three phase gasoline  generator







How to come to ITCPower

10kw/12.5kva  single/three phase gasoline  generator







Service assurance of generator and other machines



1. Before-sale Service:
We provide detailed product technical parameters for equipment choosing and system designing.



2. Service quality assurance:
Our sale staffs are all experience and professional,we can provide the most proper system design and optimized equipment for the customers.



3. After sale maintenance service:
We create files for end user and provide them follow-up service,regular return visit and permanent maintenance, We have distributors all over World that support after sale service.



4. Spare parts supply:
We provide all kinds of spare parts and technical support.



5. Main overhaul or maintenance service:
We provide perennial major overhaul and maintenance service.



Thanks for your attention to our 10Kw 60hz single phase electric open gasoline generator!
