High quality automatic steel wire mesh welding machine
Description of :
Mine support mesh welding machine network model application: the equipment for coal mine supporting network welding production line, which is suitable for coal mine supporting field, the model is suitable for the high-speed production of coal mine supporting network equipment, the welding speed, the grid size is accurate, solder joint reliability, instead of manual binding, manual welding compared with the more energy saving, high efficiency and environmental protection.
Parameters and Pictures of :
Name |
Wire mesh welding machine for coal mine |
Model |
WT-220 |
welding length |
1×2m 1.2×3m 1.5×3m 2×3m |
Welding wire diameter |
3.2~6.5mm 3.8~8mm |
Weld aperture diameter |
100mm*100mm |
Welding electrode (solder joint) |
10/12/14/16 |
Voltage |
380V 50HZ |
Power |
3KW / 4KW |
Welding Speed |
25~35 Row/min |
Weight |
2.2T,2.8T,3.2T |
Accessory equipment |
Need two sets of straight cutting machine, straightening diameter 3.2~6.5mm or 3.8~8mm steel. |
1.Delivery time: Within 5-7 days after receiving clients' payment
2.Payment Terms :
3.Packing: Wooden box free of fumigation
4.Quality Gurantee: Quality gurantee term is for 1 years, Malfunctions which are caused by operation mistakely will be reponsible for customers
1. Qualtiy Gurantee :1 years guanrantees for each machine
2. Pre-Testing before forwarding :All machines will be pre-tested to make sure it will be received
in good condition
3. Operation Video and instruction :We will provide you operation video and detailed instructions to install and you can make full use of the machine
4. Full Techinical service :Engineer is ready to provide you our full-process tracing
and instruction "
1.Alibaba Assessed Gold Supplier
2.100% Quality control before forwarding
3.Competitive price with best quality and service
1. Are you manufacturer ?
Yes we are the manufacturer and welcome to visit our factory
2. Can you change the machine voltage as our request?
Yes we can change the machine voltage as customers’ request
3. How about your after-sale service?
Our engineer can go outside to installand train your workers to operate the full machine line.
4. Warranty time of your machine?
1 years warranty time except for consumable spare parts
5. How about delivery time of your machine?
Generally it needs 10-15 days,for big machine or producing line,it will be much longer but wthin our negotiated delivery time
