Kaifeng rainbow machinery co.,ltd.
wheat unload conveyor
Introduction of wheat unload conveyor
RB series wheat unload conveyor can be used to convey granular materials horizontally, slantly and vertically such as rice, wheat, corn, soybean, sorghum, barley malt, plastic pellets, chips, resins and other granular.This kind of equipment is compact and flexible. It can loading and unloading the material quickly and easily.
wheat unload conveyor is an advanced material handling equipment. It is composed of high pressure blower, air flow control valve, separator tube, air locker, connecting pipe, suction nozzle and conveying pipelines and other components. It can convey by positive pressure or suction by under vacuum circumstance. It can also conveyed by both positive and vacuum pressure at the same time after a simple combination.
Our wheat unload conveyor is widely used in handling materials in bulk loading, bulk conveying, bulk unloading, silo to silo, stack to stack in grain, farm, railway stations, docks, grain processing and brewing industries. When using this equipment to convey grains, RB grains have been selected and dehydrated.
Model |
RB-5 |
RB-10 |
RB-15 |
RB-20 |
RB-25 |
RB-30 |
RB-50 |
RB-70 |
RB-110 |
RB-130 |
|
Fan power (kw) |
7.5 |
11 |
15 |
22 |
25 |
37 |
45 |
55 |
75 |
110 |
|
Air-lock valve (kw) |
0.75 |
0.75 |
1.1 |
1.1 |
1.5 |
1.5 |
1.5 |
1.5 |
3 |
3 |
|
Power (kw) |
8.25 |
11.75 |
16.1 |
23.1 |
26.5 |
38.5 |
46.5 |
56.5 |
78 |
113 |
|
Max horizontal distance (m) |
20 |
30 |
30 |
40 |
40 |
60 |
80 |
80 |
100 |
100 |
|
Conveying distance (m) |
5 |
8 |
10 |
10 |
15 |
20 |
20 |
30 |
30 |
35 |
|
Lift head (m) |
8.5 |
10 |
20 |
30 |
35 |
40 |
40 |
50 |
50 |
60 |
|
Capacity (t) |
5 |
10 |
15 |
20 |
25 |
30 |
50 |
70 |
110 |
130 |
|
Feeding dia (mm) |
124 |
150 |
150 |
160 |
160 |
160 |
200 |
219 |
273 |
273 |
About packaging, for small size or single machine, we can offer free fumigation wooden case with steel frame, it not only can protect machine from damage, but also avoid checking when exporting.
For multiple machines or production line, it's better to loaded in standard container 20GP, 40GP, 40HQ, usually it needs wrapped with plastic firstly, then loaded in container.
we can offer EXW, FOB and CIF terms.
EXW: You arrange the shipping details from our factory to your port by yourself.
FOB: We arrange freight transport to Qingdao, Shanghai or other ports of China, then you arrange the shipping details from China port to your country port.
CIF: We arrange all shipping details to your country port, and ensure machines smooth arrival.
1. Help you choose the most suitable machine.
2. Making the machine according to your request.
3. Give you machine’s details and video for help you use the machine more better.
4. One year warranty
5. Quality problem,we will send you the accessories.
6. Free repair whole using life without extra charge.
Kaifeng Rainbow Machinery Co., Ltd. is a domestic large-scale new energy environmental protection equipment manufacturers in China. The registered trademark is "Rainbow".
Our company has combined Research and Development, Production, Sales and Service in one, and our main product have Wood Crushing and Recycling Workstation, New Energy Particle Machinery, Feed Machinery, Organic Fertilizer Machinery, Broken machinery. Totally, have a lots of products, more than 300models, which make our company the most professional development and production of high-tech enterprises of new energy environmental protection machinery manufacturer in China.
