The corrugated compensator is a compensating device for utilizing the effective telescopic deformation of the elastic member of the corrugated compensator to absorb the dimensional change caused by the expansion, contraction or the like of the pipeline, the duct or the container, and belongs to a compensating element. Absorption of axial, lateral, and angular displacement.
Detection
Due to the different compensation forms of different types of corrugated compensators, there are mainly axial, lateral, angular and combined compensation modes. For a corrugated compensator with multiple displacements at the same time, it is necessary to synthesize various displacements to obtain the total equivalent axial displacement, and the detection is for the total equivalent axial displacement. That is to say, the detection of the nominal displacement of the corrugated compensator is the detection of the total equivalent axial displacement.
The nominal displacement of a general-purpose bellows is actually the ability of the bellows to deform a given nominal displacement. For the expansion joint (compensator) and compensator made of bellows, it is usually called the compensation amount, which reflects the ability of the bellows to absorb the displacement of the system, indicating the maximum compensation capacity of the product under certain conditions. When the bellows is in normal operation, it should absorb the displacement of the system to produce displacement deformation, and at the same time ensure a certain number of normal safe working displacement cycles. Therefore, when designing the bellows, according to the displacement of each wave, a certain number of ripples is designed. When each wave is uniformly subjected to the displacement load, and the local overload is not applied, the bellows can work normally. When the design is reasonable, it can guarantee the number of design work shift cycle life. This performance is specified in the JB/T 6169-92 "Metal Bellows" standard.
Shuntong Pipeline Manufacturing Co., Ltd. is a designated production enterprise of the Ministry of Construction of China. The company is located in the historical ancient city, China's pipe production base - Yanshan. Our company is located in Beijing and Tianjin in the north, and has convenient transportation in Huangpu Port in the east. Specializing in the production of expansion joints (compensators, metal hoses), rubber soft joints, pipe fittings (flanges, elbows, manholes, dampers, flexible waterproof casings, rigid waterproof casings, expansion joints), power plant accessories four series of products factory.
Our company has a perfect quality assurance system, has passed ISO9001-2000 international quality system certification, and has a national second-level testing room. The products are all in line with national standards. The products are slightly more than 20 provinces and cities in China, and with the United Arab Emirates, Australia, Companies in India, Japan, Canada and other countries have good business relationships.
Hebei Shengzhou Shuntong Pipeline Manufacturing Co., Ltd.
E-mail: shuntongguanjian@outlook.com
Contact: Mr. Guo
contact number:+86 18132297755
Send Inquiry to This Supplier
