Indoor P5 Rental LED Screen 640mmX640mm,Indoor Rental Led Display
Indoor P5 Rental LED Screen 640mmX640mm,Indoor Rental Led Display,Rental Led Video Wall
Indoor Rental Led Display
Rental Led Video Wall
SN |
Item |
Technical Parameters |
|||
LED Parameters | |||||
1 |
Item Name |
LED Type |
Brightness |
Wave Length |
H/V Visual Angle |
2 |
Red LED |
SMD3528 |
120-140mcd |
620-625nm |
160º/120º |
3 |
Green LED |
SMD3528 |
360-435mcd |
520-525nm |
160º/120º |
4 |
Blue LED |
SMD3528 |
80-100mcd |
470-475nm |
160º/120º |
Module Specification | |||||
1 |
Pixel Pitch |
5mm |
|||
2 |
Pixel Configuration |
1R1G1B |
|||
3 |
Module Resolution |
64 x 32 pixels |
|||
4 |
Module Pixles |
2048 pixels |
|||
5 |
Module Size |
320mm X 160mm |
|||
Cabinet Specification | |||||
1 |
Cabinet Size(W X H X D) |
640mm x 640mm x 80mm |
|||
2 |
Cabinet Resolution(dot) |
128 x 128 pixels |
|||
3 |
Module Quanity (pcs) |
8pcs |
|||
4 |
Cabinet Pixels |
16384 pixels |
|||
5 |
Pixel Density |
40000 pixels/m2 |
|||
6 |
Cabinet Materials |
Die Casting Aluminum Cabinet for rental purpose |
|||
7 |
Weight |
10.8kg per cabinet |
|||
8 |
Fly case size |
70*52*90CM( for 4 cabinets/ G.W.=78kgs ) |
|||
Whole Screen Specification | |||||
1 |
Screen Brightness |
≥2500cd/m2 |
|||
2 |
Driving Method |
1/16 scan |
|||
3 |
Best Viewing Distance |
5m - 30m |
|||
4 |
Max. Power Consumption |
750W/m2 |
|||
5 |
Average Power Consumption |
300W/m2 |
|||
6 |
Gray Level |
8bits input, 4096 levels(212) |
|||
7 |
Display Color |
16M |
|||
8 |
Frame Frequency |
≥60Hz |
|||
9 |
Refresh Frequency |
≥1200Hz |
|||
10 |
Uninterrupted Working Hours |
≥72 hours |
|||
11 |
Screen Life-span |
≥100,000 hours |
|||
12 |
MTBF |
≥5,000 hours |
|||
13 |
Discrete Blind Spot Rate |
||||
14 |
Continuous Blind Spot Rate |
None |
|||
15 |
Blind Spot Rate |
||||
16 |
Protective Scale |
For indoor use only |
|||
17 |
Screen Plainness |
||||
18 |
Power Supply Mode |
AC220±10% 50Hz/AC110±10% 60Hz |
|||
19 |
Environment Temperature & Humidity |
Temperature:-20 Celsius~+60 Celsius |
|||
Humidity:10%~90% RH | |||||
20 |
Control Mode |
Synchronous display with control PC by DVI |
|||
21 |
Control System |
Linsn, Nova-star, Colorlight or as you required |
|||
22 |
Display Content |
Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. |
|||
23 |
Interface |
Standard Ethernet |
|||
24 |
Transmission Distance |
Multi mode fiber |
|||
25 |
Certificate |
CE-EMC, CE-LVD, FCC, RoHS |
|||
