CK6432 GSK CNC Controller /CNC Lathe Fanuc siemens
1,SPECIFICATIONS
ITEMS |
Specifications |
Max.swim over bed |
Φ360mm |
Max.swim over carriage |
Φ160mm |
Max.length of work piece |
450mm |
Range of spindle speed |
150-2500rpm |
Spindle bore |
Φ60mm |
Taper of spindle bore |
MT6 |
Stations of tool carrier |
4/6/8/or gang-type tool carrier |
Min.setting unit of motor |
(Z) long 0.001mm,(X) cross 0.001mm |
Moving speed of post |
(Z) long 8 m/min,(X) cross 6 m/min |
Taper of taikstock quill |
MT4 |
Max.range of tailstock quill |
100mm |
Motor power |
4 KW |
Packing size(lenght×width×height) |
1600/1850 mm×1100 mm×1550mm |
Net weight |
1450kg |
2,Main features
11.Spindle brake way by electric brake
22.Feed of X.Z shaft are driven bu all screw with servo-motor or stepper motor
33.Imported or homemade CNC system
44.Rotary various workpiece surface automatically turning,precision maching
55.The boby of the lathe has good rigidity,the guide is treated by super audio quenching with high hardness,grinding the surface with high accuracy.
66.The carriage adopts plastic paste processing.wear small,high precision,long life.
77.Electronic hand wheel equipped,easy operation.
SPECIAL ACCESSORIES
1. Pneumatic chuck
2. Hydraulic chuck
3. Pneumatic tailstock
4. Hydraulic tailstock
5. Spring fastener
About our company
We have our own factory, We have more than 10 years of production experience in this industry. We have good quality and price.
We exported many countries, For example Italy, Russia , Greece , Turkey , Belarus , India .... etc.
Our machine through the EU CE certification
