China Top Quality Heavy Duty Slant Bed Cnc Lathe Cnc Fanuc Controller

China Top Quality Heavy Duty Slant Bed Cnc Lathe Cnc Fanuc Controller thumbnail-1
China Top Quality Heavy Duty Slant Bed Cnc Lathe Cnc Fanuc Controller thumbnail-2
China Top Quality Heavy Duty Slant Bed Cnc Lathe Cnc Fanuc Controller photo-1
China Top Quality Heavy Duty Slant Bed Cnc Lathe Cnc Fanuc Controller photo-2
US$ 35,150 - 53,100 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
BLIN
Place of Origin:
Zhejiang, China
Model Number:
BL-CBK63
Contact Supplier Request Quote Chat Now
Drilling Tapping Machine Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BLIN
Place of Origin Zhejiang, China
Model Number BL-CBK63
Year 2019
Condition New
Product Description

■ 45°slant bed, hard guideway.
■ Bed adopt China best high strength compound resin sand cast iron.
■ Guideway hardened by ultrasonic frequency and precise ground, good precision keeping
■ Aging treatment,has good vibration absorption and rigidity.
■ Guideway stick PTFE,remove creeping,obviously increase precision, wearability and anti-impact force
■ Spindle use high precision bearing.
■ Adopt 3 class gear box,suitable for heavy turning.
■ High precision ball screw, connnected with motor directly.

Item
Specification
Unit
BL-CBK63
Capacity
Max. swing dia. over bed
mm
Φ630
Max. swing dia. over slide
mm
Φ445
Max. turning dia.
(Vertical 4T/Horizontal 8T tool turret)
mm
Φ500/Φ400
Max. turning length
(Vertical 4T/Horizontal 8T tool turret)
mm
1000/800,2000/1800,3000/2800
Max. Workpiece weight
kg
1200(12'' manual chuck)
Spindle
Spindle bore
mm
Φ84
Spindle type
/
A2-11(manual chuck);A2-8(hydraulic chuck)
Spindle speed
rpm
L:20~210 M:50~525 H:155~1600
Spindle motor power
kw
11
Max. bar through dia.
mm
Φ62
Chuck size
/
12''
X/Z axes
X axes travel
(Vertical 4T/Horizontal 8T tool turret)
mm
350/270
Z axes travel
(Vertical 4T/Horizontal 8T tool turret)
mm
1000/800,2000/1800,3000/2800
X/Z axes rapid moving speed
m/min
8/8
Tool turret
Tool turret type
/
Vertical 4T/Horizontal 8T
Toolshank size
mm
32×32
Tailstock
Tailstock quill taper
/
MT4#/5#
Tailstock quill dia./travel
mm
Φ100/150
Others
X/Z axes positioning accuracy
mm
X axes≤0.024mm/Z axes≤0.032(1000),0.040mm
(2000),0.048mm(3000)
X/Z axes repeated positioning accuracy
mm
X axes≤0.007mm/Z axes≤0.009(1000),0.014mm
(2000),0.020mm(3000)
X/Z axes positive and negative difference
mm
0.012/0.016
Turning workpiece roundness
mm
0.004
Overall size
mm
2720/3980/5050×1805×1885
N.W.
kg
5000/5500/7500

Standard configuration

● FANUC 0I TF CNC Controller
● Manual chuck
● 4 station electric tool turret
● Manual tailstock

Optional configuration

● 8 station tool turret
● Hydraulic tailstock
● Chip conveyor

Why Choose us
Certifications
Our Customers
Packing & Delivery
FAQ

1.Are you factory or trading company?

We are factory and have 39 years history for machine tool manufacturing.Welcome to visi us anytime!

2.What's your payment term?

30% T/T in advanced,70% T/T balanced should be paid before shipping.

3.Do you have CE?

Yes,we have.

4.What is MOQ?

1 Unit.

Contact
Related Products

BL-S50 Slant bed cnc lathe


BL-X50 Slant bed cnc lathe
