Chinese Top Quality Heavy Duty Cnc Lathe Slant Bed With Fanuc Controller

Drilling Tapping Machine Co., Ltd
Chinese Top Quality Heavy Duty Cnc Lathe Slant Bed With Fanuc Controller thumbnail-1
Chinese Top Quality Heavy Duty Cnc Lathe Slant Bed With Fanuc Controller photo-1
US$ 30,000 - 42,350 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
BLIN
Place of Origin:
Zhejiang, China
Model Number:
BL-CK7516A/7520A/7525A
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BLIN
Place of Origin Zhejiang, China
Model Number BL-CK7516A/7520A/7525A
Year 2019
Condition New
Product Description

■ 45°(CK7516A/7520A/7525A) monoblock slant bed
■ Hard box guideway, high rigidity, suitable for heavy turning.
■ CHINA top quality, high precision.

Item
Specification
Unit
BL-CK7516A
BL-CK7520A
BL-CK7525A
Capacity
Max. swing dia. over bed
mm
Φ400
Φ500
Φ550
Max. swing dia. over slide
mm
Φ260
Φ320
Φ370
Max. turning length
mm
400/1000
500/1000/1500
500/1000/1500
Max. turning dia.
mm
Φ285
Φ370
Φ450
Max. workpiece weight
kg
360(6'' chuck)
550(8'' chuck)
700(10'' chuck)
Spindle
Spindle bore
mm
Φ57
Φ62
Φ87
Spindle type
/
A2-5
A2-6
A2-8
Spindle speed
rpm
80~3500
75~2500
100~2000
Chuck size
/
6''
8''
10''
Max. bar through dia.
mm
Φ42
Φ51
Φ73
Spindle motor power
kw
7.5/11
15
18.5
X/Z axes
X axes travel
mm
165
210
250
Z axes travel
mm
410/1030
550/1010/1550
525/1010/1550
X/Z axes ball screw O.D.
mm
Φ28/40
Φ28/40
Φ32/40(50)
X/Z axes rapid moving speed
m/min
16/20
12/16
12/16
Tool turret
Tool turret type
/
8 station
8 station
8 station
Toolshank size
mm
20×20, Φ32
25×25, Φ40
25×25, Φ40
Tailstock
Tailstock quill taper
/
MT4#
MT5#
MT5#
Tailstock quill dia./travel
mm
Φ70/80
Φ90/100
Φ100/100
Others
X/Z axes positioning accuracy
mm
0.009
0.009
0.009/0.013
X/Z axes repeated positioning accuracy
mm
0.004/0.005
0.004
0.004/0.006
X/Z axes positive and negative difference
mm
0.004
0.004
0.004/0.009
Turning workpiece roundness
mm
≤0.0025
≤0.0025
≤0.004
Overall size
mm
2370/3200×1700×1970
2860/3790/4600×1830×2020
2980/3790/4600×1850×2050
N.W.
kg
3000/4500
4500/5000/6700
4800/5000/6700

Standard configuration

● FANUC 0I TF CNC Controller
● Hydraulic chuck
● 8 station tool turret
● Hydraulic tailstock

Optional configutation

● SIEMENS 828D CNC controller
● Chip conveyor

Why Choose us
Certifications
Our Customers
Packing & Delivery
FAQ

1.Are you factory or trading company?

We are factory and have 39 years history for machine tool manufacturing.Welcome to visi us anytime!

2.What's your payment term?

30% T/T in advanced,70% T/T balanced should be paid before shipping.

3.Do you have CE?

Yes,we have.If need,we will send you.

4.What is MOQ?

1 Unit.
