Economy Y3150 small gear cutting machine
The machine is suitable for processing bulk and single-piece production spur gears, helical gears, worm and sprockets.
This machine has good rigidity, high strength, high precision, easy operation, adjustment and maintenance simple.
Hwasun milling methods can be used milling machining gear, axial or radial can be processed.
Can be configured according to the requirements of customers of Siemens CNC system, complete drum gear and
small taper bevel gear processing machine can also be heightened, lengthened to expand the machining range.
Y3150 gear hobbing machine Main data:
Main technical parameters |
Y3150 |
||
Max working module |
steel (mm) |
5 |
|
Cast iron(mm) |
6 |
||
Max diameter cutting straight Spur gear |
with column (mm) |
350 |
|
without column (mm) |
500 |
||
Max diameter cutting Cylindrical helical gear |
Rotation angle 30° |
370mm |
|
Rotation angle45° |
250mm |
||
Max vertical travel of hob (mm) |
260 |
||
Max length of cutting (mm) |
240 |
||
Distance from hob spindle to worktable surface (mm) |
Max(mm)
|
320 |
|
Min(it is 30 mm when the distance from hob spindle to worktable surface less than 85mm) mm |
25 |
||
Minimum distance from worktable surface to hob spindle axis (mm) |
170 |
||
The changeable Diameter of hob spindle(mm) |
22 27 32 |
||
Max diameter of hob (mm) |
120 |
||
Diameter of workingtable hole (mm) |
60 |
||
Diameter of worktable mandrel (mm) |
30 |
||
Speed of Hob main spindle |
Grade |
8 |
|
Range (r/min) |
50-275 |
||
The vertical feed of hob |
0.24-4.25 mm/r |
||
Main motor power |
3 kw |
||
Main motor speed |
1430 r/min |
||
Pump motor power |
0.125 kw |
||
Pump motor speed |
2790 r/min |
||
Net weight (inclusive all standard accessories) |
2500/2700 kg |
||
Size(L*W*H)mm |
1825*935*1730 |
||
Steel Horse machine,is a collection of machine development,testing,production,
sales and integration of joint-stock enterprises.Enterprises with an annual output
of 20,000 sets of various types of machine.Our company was founded in 1990,
in 1995 we shareholding system reform, found "Steel Horse Machine"brand.
With our "Steel Horse Machine" Twenty years in the machinery and equipment
manufacturing industry accumulated abundant capital and the introduction of
foreign advanced technology,in 2007 we spent a lot to create "White Horse CNC"
brand.Enterprise products have been metal processing, automotive,military,
aerospace and other key industries widely used.
Steel Horse machine"quality first,faith forever" as the purpose,we willing to
cooperate sincerely with friends at home and abroad for common development.
