China leading,Only Manufacturer M1420 cylindrical grinding machine
· Wide, precision-ground guideways ensure maximum accuracy across the entire workpiece length and accommodate high workpiece weights
· The table features large dimensions and swivels in two directions - table movement via hand-wheel or automatically via linear hydraulic feed
· The robust feed valve allows very precise micro-feed control on the X axis, including a user-adjustable dwell time at the end of the longitudinal table travel
· Hydraulic ratchet feed simplifies exact X axis positioning, limited by an adjustable zero stop, and repeated feeds by the push of a button
· The adjustable grinding spindle features superior bearings and provides for maximum precision and surface quality, plus extraordinary tool life and rigidity
· The grinding spindle motor provides up to 5.5 kW power and is designed for continuous operation
· The heavy-duty spindle head swivels 30° to the left and to the right; the work spindle head swivels 45°
· Standard inside grinder for grinding parts with diameters up to 100 mm
· Integrated rapid feed on Z axis with manual return
MODEL |
Unit |
M1420 |
|
Distance between centers |
mm |
520,750 |
|
Center height |
mm |
125 |
|
Dia Ground(O.D) |
mm |
8-200 |
|
Dia Ground(I.D) |
mm |
13~80 |
|
Max length ground(O.D) |
mm |
520,750 |
|
Max length ground(I.D) |
mm |
125 |
|
Max weight work piece |
Kg |
50 |
|
Swiveling angle |
° |
+90° |
|
Center taper(M50 |
Mt |
3 |
|
Spindle speed |
r/min |
60,85,230, 120,170,460 |
|
Wheel spindle speed |
r/min |
1820 |
|
Wheel head rapid travel |
Mm |
20 |
|
Max travel |
Mm |
150 |
|
Spindle speed |
r/min |
14000 |
|
Dimension of wheel |
mm |
max:50x25x13 min:17x20x6 |
|
Hand feed per rev |
Mm |
6 |
|
Longitudinal speed table |
m/min |
0.1-4 |
|
Center tape(mt) |
Mt |
3 |
|
Quill travel |
mm |
25 |
|
Wheel head motor power |
Kw |
3 |
|
Internal grinding |
Kw |
||
Work head motor power |
Kw |
0.25/0.37 |
|
Gross weight |
T |
2.4(520),2.9(750) |
|
Packing dimension |
cm |
192x145x205(520) 213x145x205(750) |
|
M1420 cylindrical grinding machine STANDARD ACCESSORY:
2-axis position indicator,
internal grinding equipment,
open rest, closed rest,
3-jaw chuck Ø 200 mm,
coolant system,
grinding wheel dresser,
balancing station,
balancing mandrel,
grinding wheel flange,
grinding wheel,
center point,
front and rear splatter guard,
drivers,
operating tools,
operator manual,
test certificate
