China leading,Only Manufacturer MW1420 cylindrical grinder machine
· Wide, precision-ground guideways ensure maximum accuracy across the entire workpiece length and accommodate high workpiece weights
· The table features large dimensions and swivels in two directions - table movement via hand-wheel or automatically via linear hydraulic feed
· The robust feed valve allows very precise micro-feed control on the X axis, including a user-adjustable dwell time at the end of the longitudinal table travel
· Hydraulic ratchet feed simplifies exact X axis positioning, limited by an adjustable zero stop, and repeated feeds by the push of a button
· The adjustable grinding spindle features superior bearings and provides for maximum precision and surface quality, plus extraordinary tool life and rigidity
· The grinding spindle motor provides up to 5.5 kW power and is designed for continuous operation
· The heavy-duty spindle head swivels 30° to the left and to the right; the work spindle head swivels 45°
· Standard inside grinder for grinding parts with diameters up to 100 mm
· Integrated rapid feed on Z axis with manual return
MW1420 cylindrical grinder machine STANDARD ACCESSORY:
MODEL |
Unit |
MW1420 |
M1432B |
|
Distance between centers |
mm |
500,750 |
1000,1500,2000,3000 |
|
Center height |
mm |
135 |
180 |
|
Dia Ground(O.D) |
mm |
5-200 |
8-320 |
|
Dia Ground(I.D) |
mm |
25~100 |
30~100 |
|
Max length ground(O.D) |
mm |
500,750 |
1000,1500,2000,3000 |
|
Max length ground(I.D) |
mm |
125 |
125 |
|
Max weight work piece |
Kg |
100 |
150 |
|
Swiveling angle |
° |
+90° |
+90° |
|
Center taper(M50 |
Mt |
4 |
4 |
|
Spindle speed |
r/min |
50Hz:25-380 Stepless |
50Hz:25-220 Stepless |
|
Wheel spindle speed |
r/min |
1670 |
1670 |
|
Wheel head rapid travel |
Mm |
50 |
50 |
|
Max travel |
Mm |
205 |
246 |
|
Swiveling angle |
° |
+10 |
+/-30° |
|
Internal grinding |
Kw |
1.1 |
1.1 |
|
Work head motor power |
Kw |
1.1 |
1.5 |
|
Gross weight |
T |
4.1(500), 4.3(750) |
5.3(1000), 6.1(1500), 7.9(2000), 9.9(3000) |
|
Packing dimension |
cm |
235x203x205(500) 275x203x205(750) |
322x200x205(1000) 422x200x205(1500) 540x200x205(2000) 739x200x205(3000) |
|
2-axis position indicator,
internal grinding equipment,
open rest, closed rest,
3-jaw chuck Ø 200 mm,
coolant system,
grinding wheel dresser,
balancing station,
balancing mandrel,
grinding wheel flange,
grinding wheel,
