4/0 Penguin ACSR
- 50000 Meter / Meters per Month
- Qingdao
- T/T
- 30 days
-
Ev charging cable 25mm2 --- 70mm2 Orange 1000/1500V Double insulated HV cable electric vehicle shielded cable
-
HDMI CABLE
-
PTC temperature sensing wire, pvc double insulation.
-
UL1285 PVC or silicone rubber spiral heating wire
-
PE outer layer black 2.5mm aluminum core or Galvanized steel wire electric fence underground cable
-
High quality Copper Conductor Flexible PVC RVVP Control Cable
Product Details
| Brand Name: | Gongyi Shengzhou Metal Products Co.,Ltd. | Place of Origin: | China | Model Number: | ACSR |
| Conductor Material: | Aluminum |
Product Description
Steel core aluminum strand (ACSR)is a kind of reinforced wire with single layer or multi-layer aluminum wire twisted outside galvanized steel core wire. Mainly used in power and transmission line industry.
Detailed product information:Penguin aluminum cable (NOT insulated) (ACSR) 4/0, 360 amp, 6 threads, Nominal diameter 14,31 mm.
4/0 Penguin ACSR Technical Parameters
Code name | PENGUIN | ||
| Area | Aluminum | AWG or MCM | 4/0 |
| mm2 | 107.23 | ||
| Steel | mm2 | 17.87 | |
| Total | mm2 | 125.10 | |
| Stranding and diameter | Aluminum | mm | 6/4.77 |
| Steel | mm | 1/4.77 | |
| Approximate overall diameter | mm | 14.31 | |
| Linear mass | Aluminum | Kg/km | 294.0 |
| Steel | Kg/km | 139.0 | |
| Total | Kg/km | 433.0 | |
| Rated tensile strength | daN | 3706 | |
| Maximum D.C. Resistance at 20℃ | Ω/km | 0.26750 | |
| Maximum D.C. Resistance at 75℃ | Ω/km | 0.32679 | |
| Capacity | A | 357 | |
4/0 Penguin ACSR Advantages
1. Excellent electric and mechanical characteristics.
2. Good conductivity, Resistance chemical corrosion and heat-ageing,environment stress.
3. Unit volume light, Simple in structure.
4. Convenient to use,especially for laying across rivers and valleys where special geographical terrain exist.
