LMH400 4 axis cnc horizontal machining center
Full Guard;
two exchange worktable and shield for two exchange worktable.
Worktable 1°indexing. worktable light, working signal light, spindle coolant system, 35-8000rpm,two gears spindle hydraulic unit.
Screw chip convey device. iron gasket, manual impulsator electric heat exchanger
Spindle temperature compensation, spindle and ball screw coolant device (hollow screw coolant system), Standard Tool capacity: 40 tools.
Specifications |
Unit |
No.40 |
Work table | ||
Table size |
mm |
400×400 |
Quantity of table |
|
2(rotary type) |
Exchange time of tables |
sec. |
8(60Hz)/9.6(60Hz) |
Distance from worktable to ground |
mm |
1140 |
Max. load capacity of table |
kgs |
400 |
Table indexing |
|
1°× 360° |
Travel | ||
X-axis travel |
mm |
610 |
Y-axis travel |
mm |
560 |
Z-axis travel |
mm |
560 |
Spindle | ||
Spindle speed |
rpm |
8000 Optional:10000 |
Spindle internal taper |
|
7/24 No.40 |
Spindle diameter |
mm |
Φ85 |
Distance from spindle nose to worktable face |
mm |
130~690 |
Distance from spindle center to table face |
mm |
50~610 |
Motor power of spindle |
KW |
7.5/11 |
Rapid travel | ||
X-axis rapid travel |
m/min |
30 |
Y-axis rapid travel |
m/min |
30 |
Z-axis rapid travel |
m/min |
30 |
Cutting feed |
m/min |
1~8 |
Tool magazine |
|
|
Tool storage capacity |
|
40 Optional: 60/90/120 |
Took shank |
|
BT40 |
|
Maximum tool diameter
|
mm |
Φ85 (full) Φ140 (Adjacent empty) |
|
Maximum tool weight
|
kg |
8 |
|
Maximum tool length
|
mm |
300 |
|
Time of tool change
|
sec. |
3(60Hz)/4(50Hz) |
Motors | ||
Main motor power |
kW |
7.5/11 |
X-axis AC servo motor |
kW |
4 |
Y-axis AC servo motor |
kW |
4 |
Z-axis AC servo motor |
kW |
3 |
|
Positioning accuracy
|
mm |
X±0.0025 Y/Z±0.0025 |
Repeat positioning accuracy |
mm |
X±0.0015 Y/Z±0.0015 |
Machine size |
mm |
2885x3495x2785 |
Machine weight |
kg |
8500 |
Total power |
kVA |
40 |
Air pressure |
bar |
6~8 |
