Help CenterVDL600/850/1000/1200/1500 3/4 Axis Cnc Vertical Machining Center From Dalian Factory
Related Products
-
MDH125 Cnc 5 Axis Horizontal Machining Center OKKUS$ 100,000 - 700,000MOQ: 1 Set -
VDL1300 3 Axis Cnc Vmc/cnc Vertical Machining CenterUS$ 20,000 - 70,000MOQ: 1 Set
-
VDL/VDF Series Cnc Vertical Machining Center/cnc Vmc for SaleUS$ 20,000 - 150,000MOQ: 1 Set
-
VDF Series 3 Axis Cnc Vertical Machining Center/vmc With Sliding Guide WayUS$ 20,000 - 100,000MOQ: 1 Set
-
VDF850 Box Way Cnc Vertical Machining Center FanucUS$ 20,000 - 100,000MOQ: 1 Set
VDL series 3 axis cnc vertical machining center
Such cnc vertical machining centers have following features:
1. With CE Certificate;
2. The basic parts, including in machine floor, column, spindle box, cross slide and work-table, are casted with high rigidity cast-iron, so that guarantees s stable structure and ever high quality.
3. The P4 precision angular contact bearing is applied to spindle assembled in constant house temperature environment, which guarantees the stability and high machining precision.
4. X, Y, Z axes are all equipped with high-precision ballscrews;
5. Disk-type tool magazine with the capacity of holding 24 BT40 tools simultaneously, which is powered by electric motor and operates quickly and stably.
6. The machine is equipped with full-guard and good-looking, waterproof, safe and also environment-friendly.
7. The control system is employed FANUC Oi-M control system and completely digital AC Servo Unit supported by powerful software that supports the RS232 serial interface.
Item |
VDL500 |
VDL600A |
VDL800 |
VDL1000 |
VDL1200 |
VDL1400A |
Table(L×W)(mm) |
700×320 |
800×420 |
900×420 |
1120×560 |
1220×620 |
1450×620 |
T-slot(Numbers×Width×Distance)(b/t slots) |
3×14×110 |
3×18×125 |
3×18×125 |
5×18×100 |
5×18×100 |
5×18×100 |
Table load Max(kg) |
150 |
500 |
500 |
750 |
1500 |
1500 |
The distance from spindle center line to column guide way surface(mm) |
430 |
511 |
511 |
629 |
660 |
660 |
The distance from spindle nose end face to table upper surface(mm) |
140-520 |
150-670 |
150-670 |
135-735 |
100-775 |
100-775 |
X/Y/Z travel(mm) |
450/350/380 |
600/420/520 |
800/420/520 |
1020/560/600 |
1200/600/675 |
1400/600/675 |
X/Y/Z guide way type |
Linear way |
Linear way |
Linear way |
X/Y: Linear way |
X/Y: Linear way |
X/Y: Linear way |
X/Y/Z rapid traverse speed(m/min) |
30/30/30 |
24/24/20 |
24/24/20 |
24/24/18 |
24/24/18 |
24/24/18 |
Feed rate(mm/min) |
1-10000 |
1-10000 |
1-10000 |
1-10000 |
1-10000 |
1-10000 |
X/Y/Z servo motor power(Nm) |
7/7/7 |
12/12/12 |
12/12/12 |
12/12/12 |
22/22/22 |
22/22/22 |
Spindle motor power(kW) |
3.7/5.5 |
7.5/11 |
7.5/11 |
7.5/11 |
11/15 |
11/15 |
Spindle speed range(r/min) |
60-10000 |
60-8000 |
60-8000 |
60-8000 |
45-6000 |
45-6000 |
Spindle taper |
#40(7/24) |
#40(7/24) |
#40(7/24 |
#40(7/24) |
#50(7/24) |
#50(7/24) |
Tool magazine capacity/Type |
12/drum |
16/drum 24/swing arm |
16/drum 24/swing arm |
20/drum 24/swing arm |
24/swing arm |
24/swing arm |
Tool adaptor type |
BT40 |
BT40 |
BT40 |
BT40 |
BT50 |
BT50 |
Max. Tool weight(kg) |
6 |
7 |
7 |
7 |
15 |
15 |
Max. Tool diameter/length(mm) |
80/200drum |
100/280drum 77/280swing arm |
100/280drum 77/280swing arm |
100/305drum 77/305swing arm |
127/305swing arm |
127/305swing arm |
Time of tool change(T-T)(sec) |
6-8 |
6-8/3.5 |
6-8/3 |
6-8/3 |
3.5 |
3.5 |
Air pressure requirement (MPa) |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
Power requirement (kW) |
15 |
25 |
25 |
25 |
35 |
35 |
Pls send inquiry to me for optioanl accessories and other further information about such 3 axis cnc vertical machining centers.
Payment Term:
1. 30% down payment, 70% by T/T before shipment;
2. 100% LC at sight(optional and shall be discussed before placing order);
Minimum Order Quantity:
1. 1 Set;
2. ≥2 sets, there will be much discounts.
Warranty:
1. Normally, 12 months for parts as of delivery of the machines;
Shipment:
1. For machine itself, by sea or train(inland countries).
2. For documents, by international express. eg DHL, TNT or EMS.
