VDF series 3 axis cnc vertical machining center/vmc

Recommended VMC
VDL1000(1120x560mm) 3/4-axis CNC VMC Machining Center
Machine Featurers:

1. With CE Certificate;

2. National Inspection-free products

3. Highly rigid and stable machine structure;

4. High precision Box Ways on all three-axis;

5. High precision spindle and High spindle speed: 8000~10000rpm;

6. Fast and reliable tool changing mechanism;

7. Cooling system;

8. Multi-functional CNC control system, such as: FANUC, SIEMENS, FAGOR, REXROTH, MITSUBISHI, etc;

Real Photos

VDF series 3 axis cnc vertical machining center/vmc with sliding guide way

New Design:VDF series 3 axis cnc vertical machining center/vmc with sliding guide way

Main Technical Data

Specifications

Unit

VDF850

VDF1000

VDF1200

VDF1500

VDF1800

Table (L×W)

mm

1000×500

1120×560

1220×620

1700×800

2000×800

T-slot(Numbers × Width × Distance) (b/t slots)

mm

5×18×100

5×18×100

5×18×100

6×18×125

6×18×125

Table load Max

kg

500

750

1200

2500

2500

The distance from spindle center line to column guide way surface

mm

550

629

660

850

850

The distance from spindle nose end face to table upper surface

mm



150~660

135~735

90~765

200~962

180~942

X/Y/Z travel

mm

850/510/510

1020/560/600

1200/600/675

1530/800/762

1850/800/762

X/Y/Z guide way type



box way

box way

box way
Y-axis 4 rails

box way
Y-axis 4 rails

box way
Y-axis 4 rails

X/Y/Z rapid traverse speed

m/min

20/20/18

24/24/18

20/20/18

15/15/12

15/15/12

Feedrate

mm/min

1~7600

1~10000

1~10000

1~6000

1~6000

Positioning accuracy

mm

X:0.025

Y/Z:0.020

X:0.025

Y/Z:0.020

X:0.030

Y/Z:0.020

X:0.030

Y/Z:0.020

X:0.030

Y/Z:0.020

Repeat positioning accuracy

mm

X:0.010

Y/Z:0.008

X:0.010  Y/Z:0.008

X:0.013

Y/Z:0.008

X:0.013

Y/Z:0.008

X:0.013

Y/Z:0.008

X/Y/Z servo motor power

kW

3/3/3(4.2/4.2/4.2)

3/3/3

3/3/3

3/3/3

3/3/3

(Nm)



12/12/12

12/12/12

22/22/22

22/22/22

22/22/22

Spindle motor power

kW

7.5/11

7.5/11

11/15

11/15

wide range

motor

11/15

wide range

motor

Spindle speed range

r/min

60~8000

60~8000

45~6000

45~6000

45~6000

Spindle taper



#40(7/24)

#40(7/24)

#50(7/24)

#50(7/24)

#50(7/24)

Tool magazine capacity/Type



20/drum
24/swing arm

20/drum
24/swing arm

24/swing arm

24/swing arm

24/swing arm

Tool adaptor type





BT40

BT50

BT50

BT50

Max. Tool weight

kg

7

7

15

15

15

Max. Tool diameter/length

mm

77/305

77/305
swing arm

127/305
swing arm

110/350

swingarm

110/350

swingarm

Time of tool change(T-T)(sec)



6~8/3

6~8/3

3.5

3.5

3.5

Air pressure requirement

mPa

0.5

0.6

0.6

0.6

0.6

Power requirement

kW

25

25

35

40

40

Overall dimension(L×W×H)

cm

335×228×265

282×282×248

288×282×280

430×348×312

516×348×3120

Net weight

kg

7000

8000

8500

14000

14500
