VDL600 cnc vertical machining center/cnc vmc
l With CE Certificate;
l National Inspection-free products
l Highly rigid and stable machine structure;
l High precision slide ways on three-axis;
l High speed, high-precision spindle;
l Fast and reliable tool changing mechanism,
l Cooling system;
l Multi-function CNC control system for your choice: Fanuc, Siemens, GSK and so on;
New Design:
Specifications |
Unit |
Parameter |
Table (L × W) |
mm |
800×420 |
T-slot (Numbers × Width × Distance) (b/t slots) |
mm |
3×18×125 |
Max Table load capacity |
kg |
500 |
Distance from spindle center line to column guide way surface |
mm |
511 |
Distance from spindle nose end face to table upper surface |
mm |
150~670 |
X/Y/Z travel |
mm |
600/420/520 |
X/Y/Z guide way type |
|
Linear way |
X/Y/Z rapid traverse speed |
m/min |
24/24/20 |
Feed rate |
mm/min |
1~10000 |
X/Y/Z servo motor power |
KW |
3/3/3 (1.2/1.2/1.8)(1.8/1.8/2.5) |
X/Y/Z servo motor torque |
N.m |
11/11/11 |
Positioning accuracy |
mm |
X/Z: 0.020 Y: 0.016 |
Repeat positioning accuracy |
mm |
X/Z: 0.008 Y: 0.006 |
Spindle motor power |
kW |
7.5/11 |
Spindle speed range |
r/min |
60~8000 |
Spindle taper |
|
#40(7/24) |
Tool magazine capacity / Type |
|
16/drum 24/swing arm Opt |
Tool adaptor type |
|
BT40 |
Max. Tool weight |
kg |
7 |
Max. Tool diameter/length |
mm |
100/280 drum 77/280 swing arm |
Time of tool change (T-T) |
sec |
6~8/3.5 |
Air pressure requirement |
MPa |
0.6 |
Power requirement |
kW |
25 |
Overall dimension (L × W × H) |
mm |
2310×2040×2337 |
Net weight |
kg |
4800 |
