MDV75 3 axis cnc vmc with 4th axis optional

FOB Price

USD $50,000 - $200,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Dalian China;
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	DALIAN	Place of Origin:	Liaoning, China	Model Number:	MDV75 high speed cnc vmc
Type:	Vertical	Certification:	CE; ISO9001:2008; GB/T19001:2008	After-sales Service Provided:	Engineers available to service machinery overseas
Warranty:	12 months	Weight:	32500kgs	Dimension(LWH):	5530x8195x3100mm
Voltage:	Customer's Requirement	Condition:	New	Power(W):	7.5/11kW

Product Description

MDV75 high speed cnc vmc

Std Configuration

l Full - enclosed protective cover, XYZ track slip surface protection, and protection of steel, cutting oil installations(Cutting Oil separating tank)

l Work lights spindle lubricating oil temperature adjusting device, rear - mounted spiral chip removal device on each one, the level of alignment component

l Mechanical handling parts, automatic cut - off devices, electrical spare fuse

l FANUC 18 I control system of 10.4'' color LCD displays, auto power off function, memory length of 160 M procedures, electric leakage protection device

l Electric heat exchanger equipped with 20 disc type tool changer, and silver HIWIN Ball screws

l MDV55 configure the original Japanese OKK spindle -8000rpm gear spindle 117.5KW 25, MDV75 configuration IBAG

l 25~6000rpm gear spindle 117.5KW

l When exporting countries and regions need different when transformer no further charges.

l Standard accessories:

l Iron gasket for Machine Tool and Tool box wrenches, basic installation instructions, maintenance manuals and electrical manual NC system information;

l CE Certificate is provided;

l High-prision spindle and high spindle speed: 6000~13000rpm;

Main Technical Data

Specifications	Unit	Parameter
Table(L×W)	mm	1550x740
T-slot(Numbers×Width×Distance)(b/t slots)	mm	22×140×5
Table load Max	kg	1500
The distance from spindle center line to column guide way surface	mm	810
The distance from spindle nose end face to table upper surface	mm	150-810
X/Y/Z travel	mm	1530/740/660
X/Y/Z guide way type		Sliding Guide way
X/Y/Z rapid traverse speed	m/min	24/24/20
Feed rate	mm/min	1~10000
X/Y/Z servo motor power	Nm	4.0/4.0/7.0
Positioning accuracy	mm	±0.003(JIS)/0.008(VDI)
Repeat positioning accuracy	mm	±0.002(JIS)/0.004(VDI)
Spindle motor power	kW	7.5/11(SPECIAL:11/15)
Spindle speed range	r/min	6000(Second level gear speed) (Special:8000rpm(Second level gear speed/13000rpm MS)
Spindle taper		50
Tool magazine capacity/Type		20(Special:30)
Tool adaptor type		JISB6339 50T
Max. Tool weight	kg	20
Max. Tool diameter/length	mm	Φ110 (30Drum:Φ103)/350
Time of tool change(T-T)	sec	(T-T), 5.9 (C-C) Speed as per the tool weight
Air pressure requirement	MPa	0.4~0.6
Net weight	kg	10500
Repeat positioning accuracy	mm	X±0.0015 Y/Z±0.0015
Machine weight	kg	32500
Machine covers an area of size	mm	5530×8195
