CDL6246x1500 gap bed lathe machine
CDS6250(Ø500mm) Conventional Horizontal Lathe Machine
1. I.D. & O.D. cylindrical turning,
2. end face turning,
3. I.D. & O.D. cone turning,
4. grooving,
5. threading;
Specifications |
Unit |
Parameter |
Max swing over bed |
mm |
410 |
Max swing over carriage |
mm |
230 |
Center distance |
mm |
1000 |
Max swing in gap |
mm |
640 |
Width of bed |
mm |
300 |
Spindle nose |
|
C6/D6 |
Spindle bore |
mm |
48/52 |
Taper of spindle bore |
|
M6 |
Spindle speeds |
rpm |
32~2000 (12 speed) |
Range of inch threads |
TPI |
2~56 |
Range of metric threads |
mm |
0.5~14 |
Range of module threads |
mm |
0.5~14 |
Range of Diametrical pitch thread |
D.P |
2~56 |
Longitudinal feed |
mm/rev |
0.06~0.82 (0.002"-0.032"/r) |
Cross feed |
mm/rev |
0.017~0.242 (0.007"-0.0095"/r) |
Lead screw diameter |
mm |
36 |
Pitch of lead screw |
mm |
6 |
Taper of tailstock quill |
|
M4 |
Travel of tailstock quill |
mm |
150 |
Diameter of tailstock quill |
mm |
60 |
Power of main motor |
kW |
3/4.5 (4/6HP) |
Power of coolant motor |
W |
90W(0.125HP) |
Net weight |
kg |
1390 |
Standard: spindle head is C6, Spindle hole: Φ48 mm
Spindle head is D6, spindle hole: Φ52 mm;
Guide rail width:300mm;
Guide rail hardness:HRC50, Depth1.5mm;
Hardened and ground guide ways;
Maximum load capacity between two centers: 300kg
Standard: the lathe is equipped with left-handed wheel;
Right-handed wheel shall be informed specially when placing order;
Three boxes are all self inside lubricating;
Machine tool bed box are non-clutch;
CE Certificated are not provided;
