VMC600 VMC650 GSK Cnc Controller Milling Machine Center Price

FOB Price

US$ 23,000 - 48,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HANKUI/Hunk	Place of Origin	Shandong, China
Type	Vertical	Certification	ISO CE SGS
After-sales Service Provided	Engineers available to service machinery overseas	Warranty	12 Months
Weight	2600kg	Dimension(LWH)	220021002200
Voltage	Customer's Requirement	Condition	New
Power(W)	5.5kw

Product Description

Our Company

VMC600 VMC650 GSK Cnc Controller Milling Machine Center Price

Jinan Hankui international trade co., ltd

Jinan Hankui International Trade Co.,Ltd is a subsidiary company of Shandong Hunk Precision Machinery Co.,Ltd. It is a machine tools company, located in the beautiful capital Jinan city, integrated with manufacturing, processing and sales.

It was set up by the former Jinan Machine Tools Factory Emplogyees, who have more than 20years experience of machining tool design and assembly.

Our Service

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Product Description

Fagor Cnc Control Small 3 Axis Cnc Drilling Machine Center Price VMC 600L

Main Features:

1. Imported high speed and high precision spindle.

2. Standard tool magazine.

3. High strength resin sand casting.

4. C3 grade ball screw

5. Imported cylindle from Taiwan

6. NSK bearing imported from Japan

7. Automatic intermittent lubricate system

8. Fully enclosed cover

9. Fanuc, Simens, Mitsubishi, Syntec CNC control system

Technical parameter

ITEM	UNIT	VMC350L	VMC460L	VMC600L
Table size	mm	690*230	800×300	800*360
Load capacity	kg	150	200	350
T slot		3-16-63	3-14*80	3-14*115
X-axis travel	mm	350	460	600
Y-axis travel	mm	260	320	400
Z-axis travel	mm	350	460	500
Distance from Spindle center to table	mm	90-440	900 - 550	100-600
Distance from Spindle center to column slide way	mm	294	395	430
Tool shank		BT30	BT30/BT40	BT40
Spindle speed	rpm	10000	10000	10000
Spindle motor power	kw	2.2	3.7	5.5
Max. diameter of tool	mm	Φ30/Φ80	Φ80/Φ120	Φ120X200
Max. length of tool	mm	120	200	350
Max. weight of tool	kg	3	6	8
X/Y -axis rapid moving speed	mm	10000	10000	10000
Z-axis rapid moving speed	mm	10000	10000	10000
Feed rate	mm	1-4000	1-4000	1-10000
Positioning accuracy	mm	0.02	±0.012	0.01
Repeated positioning accuracy	mm	0.01/300	0.007	0.007
Out dimension	mm	1520X1300X1800	1850X1800X1900	2200X2100X2200
Machine weight	kg	1500	2500	3500

VMC Machine Center

VMC350 Small Cnc Machine Center

Standard configuration

1) 2.2kw servo motor, spindle speed 8000rpm, BT30
2) 12(standard) tools, Umbrella-type tool magazine,
3) Nozzle coolant, Belt Driven,
4) HIWIN (Taiwan) ballscrew,
5) PMI (Taiwan) linear guide way,
6) ROYAL/POSA (Taiwan) spindle,
7) Schneider( France) electric parts,
8) Heat exchanger

Optional configuration:

1)	No tool magazine
2)	Spindle speed 12000r (with oil cooler)
3)	4th axis ( bar type, made in China), center height 110mm, with tail stock
4)	4th axis ( bar type, made in China), center height 125mm, with tailstock

VMC460L Cnc Milling Machine Center

1) 3.7kw servo motor, spindle speed 8000rpm, BT30
2) 12(standard) tools, Umbrella-type tool magazine,
3) Nozzle coolant, Belt Driven,
4) HIWIN (Taiwan) ballscrew,
5) PMI (Taiwan) linear guide way,
6) ROYAL/POSA (Taiwan) spindle,
7) Schneider( France) electric parts,
8) Heat exchanger

VMC600L Cnc Machining Center

1) 5.5kw servo motor, spindle speed 8000rpm, BT40
2) 16(standard) tools, Disc type tool magazine,
3) Nozzle coolant, Belt Driven,
4) HIWIN (Taiwan) ballscrew,
5) PMI (Taiwan) linear guide way,
6) ROYAL/POSA (Taiwan) spindle,
7) Schneider( France) electric parts,
8) Heat exchanger

VMC850L Cnc Machining Center

1)7.5kw servo motor, spindle speed 8000rpm, BT40
2) 24(standard) tools, Disc type tool magazine,
3) Nozzle coolant, Belt Driven,
4) HIWIN (Taiwan) ballscrew,
5) Roxreth (Germany) linear guide way,
6) ROYAL/POSA/Kenturn (Taiwan) spindle,
7) Schneider( France) electric parts,
8) Heat exchanger

VMC1060L Cnc Milling Machine

1)11kw servo motor, spindle speed 8000rpm, BT40
2) 24(standard) tools, Disc type tool magazine,
3) Nozzle coolant, Belt Driven,
4) HIWIN (Taiwan) ballscrew,
5) Roxreth (Germany) linear guide way,
6) ROYAL/POSA/Kenturn (Taiwan) spindle,
7) Schneider( France) electric parts,
8) Heat exchanger

VMC1160L Cnc Milling Machine Center

VMC1270L /VMC1380L /VMC1580L

1)15kw servo motor, spindle speed 8000rpm, BT40
2) 24(standard) tools, Disc type tool magazine,
3) Nozzle coolant, Belt Driven,
4) HIWIN (Taiwan) ballscrew,
5) Roxreth (Germany) linear guide way,
6) ROYAL/POSA/Kenturn (Taiwan) spindle,
7) Schneider( France) electric parts,
8) Heat exchanger
