VMC850L CNC Machining Center Hobby CNC Milling Machine

Name: VMC850L CNC Machining Center Hobby CNC Milling Machine
Brand: HANKUI
Availability: InStock

FOB Price

US$ 19,900 - 37,900 / Set

1 Set(Min. Order)

Port Qingdao Port for VMC850L CNC Machining Center Hobby CNC Milling Machine
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HANKUI	Place of Origin	Shandong, China
Model Number	VMC850L	Type	Vertical
Certification	ISO9001 CE	After-sales Service Provided	Engineers available to service machinery overseas
Warranty	12 Months	Weight	5500KG
Dimension(LWH)	2600X2200X2550mm	Voltage	Customer's Requirement
Condition	New	Power(W)	7.5kw

Product Description

Technical parameter

ITEM	UNIT	VMC850L	VMC1060L
Table size	MM	1000*500mm	1200*600
T slot	MM	5-18*90	5-18*19
Load capacity	KG	500	800
X-axis travel	MM	800	1000
Y-axis travel		500	600
Z-axis travel		500	600
Distance from Spindle center to column slide way		550	650
Distance from Spindle center to table		150-650	120-720
Tool shank		BT40	BT40
Spindle speed	RPM	8000	8000
Spindle servo motor power	KW	7.5	11
X/Y/Z-axis feedrate	Mm/min	1-10000	1-10000
X/Y/Z-axis rapid moving speed	m/min	48000	36000
X/Y/Z-axis positioning accuracy	MM	0.008	±0.01
X/Y/Z-axis repeated positioning accuracy	MM	0.002/300	±0.003
Out dimension	M	2.62.22.55	32.52.9
N.W.	KG	5500	6500

Main Features

⑴ Base, sliding block, working bench, vertical column , spindle box and other main basic parts adopt HT300 cast iron; base is box type structure with symmetric compact and reasonable structure which ensures the basic parts of the high rigidity and bending resistance performance.

⑵ The guide rail of X, Z, Y axis are use Taiwan HIWIN company's heavy load 45# linear ball guide, has the advantages of fast speed, Eliminate intermittent creep, high rigidity, low friction, low noise , low temperature rise and so on.

(3) The feed of X, Y, Z direction adopts the inner loop preloading large-lead ballscrew with double nut so it is of high feed speed. The drive motor connect with screw straightly via elastic coupling.

(4) Guide rail and ball screw of X, Y, Z direction are all use protection device to ensure that the screw and the guide is clean and the accuracy and life of machine tool's transmission and movement.

(5) The machine tool external protection of machine tool uses the full protection structure. It is convenient operation, safe and reliable, and nice shape.

Application

It can finish clamping one-time of various dishes, plates, shell, cam, mold and other complex parts. It can complete the drilling, milling, boring, reaming, expansion, and other rigid tapping process . so it is suitable for many varieties, medium and small batch production.

Our Company

Jinan Hankui international trade co., ltd, which is the subsidiary corporation of Shandong Hunk precision machinery Co., Ltd., is a CNC machine tools company, located in the beautiful capital Jinan city, integrated with manufacturing, processing and sales. The plant area is about 10,000 square meters. We have a number of R&D persons and technicians who have more than 20 years experience of machine tool design and assembly. We have mastered the advanced machine tool technology and were dedicating to service customers domestic and abroad and welcomed deeply.

The main products are horizontal / vertical/ gantry machining center, flat / slant bed CNC tuning lathe, CNC vertical turning lathe etc. With superior equipment, advanced technology, detection devices, the imported parts from Taiwan, Japan, Germany etc., we can manufacture the high quality machine tools. And we also take over the metal products and spare parts machining in good quality.

Testing & Packing

FAQ

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available, We need your machines running in order to keep your business running.

Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.

Q: What sales terms do you have?
A:T/T, L/C,West Union.

Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings or Video Support,

Q: What is your delivery time?
A: Depending on the type of machine, duration of 10 days to 45 days from date of order.
