Help CenterHigh Efficiency Gold Separating Machine Mining Shake Table
Related Products
-
Mining Alluvial Gold Separator Machine ManufactureUS$ 1,600 - 2,600MOQ: 1 Set -
Vibrating Screen Separator Gold Mining MachineUS$ 10,000 - 35,000MOQ: 1 Set
-
Vibrating Screen Separator Vibratory Sieve Shaker Screens ManufacturersUS$ 25,000 - 35,000MOQ: 1 Set
-
Mini Gold Wash Plant/Ore Shaking Table/Mining EquipmentUS$ 1,600 - 2,600MOQ: 1 Set
-
Mineral Concentrator New Design Crushed Mining Heavy Duty Machines Shaking Table for Gold, Zircon, Chrome, Tin Ore SeparationUS$ 1,600 - 2,600MOQ: 1 Set
Gold separating machine mining shake table are designed to wet gravity-based separation of minerals and other granular materials. There are many applications where the concentrating gold separating machine mining shake table is of particular value and cannot be equaled for economical and efficient performance. They are effective in processing precious and base metal, rare metal and non-metallic minerals. The gold separating machine mining shake table have three distinct deck designs available. The course ore deck is designed for recovering particles sized from 0.5 mm to 2 mm; the fine sand deck is designed for recovering fine particles in the range of 0.074 mm to 0.5 mm; the slime deck is designed for recovering super extremely fine particles in the range of 0.05 mm to 0.074 mm.
The course ore deck is designed for recovering particles sized from 0.5 mm to 2 mm; the fine sand deck is designed for recovering fine particles in the range of 0.074 mm to 0.5 mm; the slime deck is designed for recovering super extremely fine particles in the range of 0.05 mm to 0.074 mm.
Construction and mechanical features
Head Motion shaking tables are furnished with a totally enclosed self-oiling head motion of heavy cast iron to contain an oil reservoir for perfect splash lubrication.This feature protects the moving parts, reducing operating and maintenance costs to a minimum.
ecks The decks are constructed of steel framework and covered 16mm fiberglass with emery, this cover its strength reaches as high as 70% of steel, the features of this design are stronger, wear-resistant,
corrosion-resistant, and no distortion, it lengthens the working-life of machine and thus allows machine perform perfectly on different mineral and different weather condition.
Support types Traditionary type, 10# channel steel support or 20# channel steel support are available.
Feed and Water Box A wooden feed distributing box with hopper and a long water
box are attached to the iron of the deck, giving a very even distribution of feed and water.
Technical Specification The Shaking Tables have three distinct deck designs available.
The coarse ore deck is designed for recovering particles size from 0.5 mm to 2 mm; the fine sand deck is designed for recovering fine particles in the range of 0.074
mm to 0.5 mm; the slime deck is designed for recovering super extremely fine particles in the range of 0.02 mm to 0.074 mm.
Construction of gold separating machine mining shake table
gold separating machine mining shake table Head Motion:The head motion is of rugged construction and requires minimum maintenance. Its internal mechanism is splash lubricated from an integral oil sump.
gold separating machine mining shake table Decks: The decks are built of 16 mm zircon-reinforced fiberglass with fabricated steel frames at the bottom and are easy to clean, requiring little maintenance. The specific gravity of fiberglass made into decks is one third of that of steel, while its strength reaches as high as 70% that of steel. This fiberglass desks also has the characteristic of water-resistance and corrosion-resistance and can hold the shape unchangeable at ±50.
gold separating machine mining shake table Feed and Water Box: A wooden feed distributing box with hopper and a long water box are attached to the iron of the deck, giving a very even distribution of feed and water.
Pre-sale services:
a. Professional engineer design the production line for you
b.Recommend suitable equipment according to your special demand.
During-sale services:
a.Pre-check and accept products before delivery
b.Send technicians to the jobsite for guiding the installation and adjustment
c.Training operators and finishing the check to satisfy your requiremnet
After-sale services:
a.Common problem can be solved through web in 24 hours,complex problem can be reacted immediately in 24 hours and solved as soon as possible
b.To establish long-term friendship, we will regulary contact with our customers.
Packing
FLC&LCL Export standard container 20/40 GP.
Steel support & iron sheet sea-worthy package.
Load: export software scientific loading work
Transportation
By sea freight.
MSK/MSC/APL/EMC/WANHAI/KLINE
Air delivery services
We will remind you before boat arrives.
