The PLC control system,touch screen man machine interface.
Automatic identification coated glass or lowe glass.
membrane layer.
Can be online and offline lowe glass cleaning.
Cleaner wind automatically adjust according to the glass
thickness(select)..
Digital control energy saving system production line.
continuous work.
Low-e glass cleaning brush speed to variable frequency drive.
Glass automatic positioning system.
Automatic detection of glass length,height;Automatically
adjust the best inflatable space,save gas.
Tablet press with triaxial linkage;with piecewyse,tabletting,
inflatable one function.
of double insulating glass can choose inflatable
function.
Ensure the hollow glass oxygen content is equal to 85%.
Side size inflatable function.
Aluminum frame automatic positioning system.
With remote communication function(select).
| Maximum size of processed glass | 2500x3000mm |
| Minimum size of glass processing | 300x450mm |
| Cleaning the glass thickness | 3-15mm |
| Insulating glass thickness | 10-48mm |
| Cleaning glass speed | 0-12/min |
| Glass cleaning brush | 6root（2rootLOW－Ebrush） |
| Transferring glass speed | 45m/min |
| Sucker suction machine are | 6kg/a |
| Charging time | 3-5seconds(900mmx1200mm) |
| Rumtime environment temperature | 7-50℃ |
| Electric power | 3p380V/1P+N220V50Hz38kw |
| Compressed air | 0.8m3/min Air pressure0.7mpa |
| Water | water0.5t/h |
