Waterjet Ceramic Tile Cutting Machine
- Dalian
- T/T Credit Card
You May Like
-
CNC Water Jet Stone Cutter
-
APW Ceramic Tile Cutting Machine
-
Top Quality Made in Italian Control Water Jet Cutting System
-
APW Diamond Orifice Waterjet Cutting Machine for Metal Stone Glass With Italian CNC Control System Double Intensifiers Pump
-
CNC 5-Axis Waterjet Cutting Machine,3000X2000X150mm
-
APW Waterjet Cutting Machine,mini Bridge Style
Product Details
| Brand Name | APW | Model Number | APW-Waterjet ceramic tile cutting machine | |
| Certification | CE TUV | |||
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1 year | |
| Weight | 2000 | Dimension(L*W*H) | 3000x2000x150mm | |
| Condition | New | Voltage | 380V | |
| Power(W) | 37KW | Type | Tile Cutting Machine | |
| Tile Type | Ceramic |
Product Description
Waterjet ceramic tile cutting machine are the most flexible and cost-effective cutting machine available. As the leader provier of waterjet cutting machine, APW's objective was to harness state-of-the-art technologies to make high-pressure abrasive jet machining practical, affordable, and easy to use.

All-powerful Science & Technology Stock Co.,Ltd, a sino-US joint venture, which was established at 2001 and located in the Export Processing Zone of Liaoning Provence, All-powerful is the largest new high-tech enterprise integrated the reserch and development of ultral-high pressure Water jet cutting machine (Waterjet ceramic tile cutting machine ), and an important base for developing high-end ultral-high pressure water jet industry of china.
Our mission is to help our customers solve their manufacturing challenges and achieve their highest level of productivity,precision and accuracy.
Waterjet ceramic tile cutting machine can cut almost any material.
The features Waterjet ceramic tile cutting machine
1 It does not cause heat effect or detormation or tiny cracks
2 It can cut any complex and flat figures
3 Narrow kerfs
4 Smooth incision
5 Minimize dust and toxic fumes, provice healthier working environment
6 It can be adjested easily and quickly by the designs and materials
7 Low processing cost in unit time
8 Components are of high quality and spare parts are cheap
9 Drilling holes to avoid water permeate the composite materials
10 Reduce setting time and fixture cost
The cutting speed for waterjet ceramic tile cutting machine
The cutting speed of waterjet ceramic tile cutting machine varies depending on the material, thickness, desired cut quality, water pressure and the machine itself configuration. Generally for APW waterjet, you could find the following speed just for your reference.
| Material | Thickness(mm) | Cutting speed of 300Mpa pump(mm/min) | Cutting speed of 380Mpa pump(mm/min) |
| Marble | 20 | 300 | 380 |
| 30 | 200 | 300 | |
| Granite | 20 | 250 | 330 |
| 30 | 150 | 200 | |
| Glass Brick | 12 | 800 | 960 |
| Glass | 5 | 1200 | 1500 |
| 10 | 500 | 600 | |
| 20 | 350 | 420 | |
| Glue Chipped Glass | 10 | 450 | 540 |
| Sponge | 50 | 5000 | 6000 |
| Foam | 50 | 5000 | 6000 |
| Wood | 10 | 1000 | 1200 |
| 50 | 200 | 240 | |
| Steel | 2 | 600 | 720 |
| 4 | 400 | 500 | |
| 6 | 300 | 420 | |
| 8 | 200 | 300 | |
| 10 | 120 | 200 | |
| 15 | 75 | 120 | |
| 20 | 30 | 50 | |
| 60 | 12 | 20 | |
| Laminates | 10 | 1500 | 1800 |
| Aluminum | 5 | 350 | 500 |
| Copper | 5 | 350 | 420 |
Glass Fiber Reinforced Plastic | 2 | 1200 | 1500 |
Waterjet ceramic tile cutting machine is made up of several critical key componnents, such as intensifier pump; cutting table with cutting head; CNC controller; auto abrasive delivery system.

Dual-Core Waterjet Debut
APW pioneered “Dual-Core” waterjet, which integrated SIEMENS motor, imported REXROTH hydraulic pump and hydraulic valves assembly, American A&V intensifier, American high pressure tube and stainless steel water tank. This dual intensifiers design (for mini waterjet cutting machine ) represents another landmark in APW history.
They has been widely used in all APW waterjet series. UP to now, APW is still the only waterjet manufacturer holding this advanced technology in China.
Imported components
We adopt the imported component of waterjet ceramic tile cutting machine like Rexroth hydraulic pump; USA intensifier; Siemens motor;Omron PLC; Yaskawa servo drive; Yuken direction control valves etc. The whole parts of Intensifier are assembled in USA (not just some parts), most of the smaller parts are also imported from USA to ensure its good stability during cutting, durability and long working service life.
Waterjet ceramic tile cutting machine be packed in standard packing, suitable for long distance ocean transportation and well protected against damage, moisture, shock, rust and handing.
Waterjet ceramic tile cutting machine have got the consistant high praise from the customer at home and abroad during the 14 years development, there are many successful stories related to APW cnc water jet cutter, we are looking forward to seeing you in our picture wall.
1. What are the benefits of purchasing a waterjet ceramic tile cutting machine comparing CNC plasma or a laser ?
Versatility
Waterjet ceramic tile cutting machine can cut almost anything – from metal to stone to glass to composites to ceramic.
Laser and plasma cut with heat, and so can only cut materials that have the right thermal properties. Metal is almost always the target material in industry for these heat-based processes. And mild steel is almost always the metal that is cut by them. In addition, plasma can only cut things that are electrically conductive. To optimize laser and plasma cutting, change to gasses is required. No change to waterjet parameters, except speed, is usually required for any material.
Thickness
Waterjet ceramic tile cutting machine can cut very thin and up to 150mm (sometimes more) of any metal, glass, stone, composite, etc.
Laser cuts very thin and up to 20mm.
Plasma cuts from about 25mm up to 30mm.
Edge finish
Nothing cut by a plasma or laser will be as high of quality of an edge as a waterjet ceramic tile cutting machine. We leave behind a smooth edge. No heat affected zones or mechanical stresses are introduced. The plasma and laser cut with heat (we cut with supersonic erosion). Plasma and laser therefore will leave behind a heat affected zones, mechanical stresses, and especially with plasma, dross 'drips' on the edge.
Please contact us for more information of our waterjet ceramic tile cutting machine.
2. What kind of material does your waterjet ceramic tile cutting machine can cut?
There are plenty materials our waterjet ceramic tile cutting machine can cut , such as metal stone glass foam plastic rubber, ect.
4-axis was professionally designed for mable pattern and medallion.
5-axis was professionally designed for 3D materials.
3. What's your waterjet ceramic tile cutting machine's max.cutting thickness?
The max.cutting thickness of our waterjet ceramic tile cutting machine depends on the materials you cut .
Generally speaking, the thickness of our waterjet ceramic tile cutting machine can be up to 150mm, virtually Z constraint is the only limit to thickness.
More information about APW waterjet ceramic tile cutting machine price pls contact us at hotline: +86-024-24699053
