Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM

Beijing V-Young Tech. Development Co.,LTD
Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM thumbnail-1
Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM thumbnail-2
Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM thumbnail-3
Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM thumbnail-4
Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM photo-1
Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM photo-2
Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM photo-3
Customized Single Output 10W AC DC Converter, PCB Mount Power Supply,5/12/15/24V Output Voltage, OEM photo-4
US$ 5 - 10 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
V-YOUNG
Place of Origin:
China
Model Number:
VAS10 Series
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China Mainland
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name V-YOUNG
Place of Origin China
Model Number VAS10 Series
Type Other, AC/DC Converter
Size 62*45*22.5
Output Power 1 - 50W
Output Type Single
Output Current 3.6, 3, 1.25, 1, 0.63, 0.31 or customized
Output Voltage 3.3, 5.05, 12, 15, 24, 48 or customized
Input Voltage 165~265, 85~265Vac

  • AC DC converter

  • 10W AC DC converter

  • Advantage:
    1. Imported famous brand raw materials, such as chip of Fairchild or PI and more. All products meet RoHS, UL, and CE.
    2. Built-in filter, no need add external circuit
    3. Strict standard manufacturing technique. Product reliability testing, thermal design, strong impact test, 100% load aging test and more.
    4. Power design with big allowance, 3000VAC isolation.  Low ripple, low noise, over current, over heating, short circuit protection, meet EMC and safety test, low power consumption, green environmental protection.
    5.3 years warranty.
             All above reasons to make our products high stability, high power density, high efficiency, small size, strong performance of industrial products. And welcome custom too.
    Specifications details:

  • Output voltage: 5, 12, 15, 24V

  • Output mode: single

  • Input voltage: 220V

  • Input voltage range: N of 165-265V AC, W of 85-265V AC

  • Packing: SIP

  • Industrial standard pin-out

  • Output voltage accuracy: ±1%

  • Line regulation: ±0.2% (maximum)

  • Load regulation: ±0.5% (maximum)

  • Ripple and noise: 50mVp-p (Vo≤5V DC), 100mVp-p

  • Temperature coefficient: ±0.1%

  • Isolation voltage: 2500V AC/1 minute

  • Switching frequency: 100kHz

  • Efficiency: 72%

  • Hand soldering time: 5s

  • Operating temperature: -25 to +85°C

  • Storage temperature: -40 to +105°C

  • Cooling: natural convection cooling

  • Relative humidity: 10 to 90%

  • Short-circuit protection

  • Sizes: (L) 1.46 x (W) 0.71 x  (H) 1.63 inches

  • Dimension: 62 * 45 * 22.5 mm


Product Tags: 10W AC DC PCB power supply , 5/12/15/24V power supply , Single output power supply , PCB mount power supplies , 10W AC DC Converter , AC DC Converter
