Physical Characteristics
Dimensions: 49mm x 38mm x 20mm
Weight: 37g
Voltage : 5VDC
Current : 400mA
Performance Characteristics
Image (Pixels): VGA 640x480 pixels
Light Source: Aiming& illumination: 617nm LED
Field of View: 45° H X 35° V
Roll/Pitch/Yaw: 360°, ±65°, ±60°
Print Contrast: 25% minimum reflective difference
Motion Tolerances： up to 15cm persecond
Symbology Decode Capability
1-D:
UPC-A, UPC-E, EAN8, EAN13, ISSN, Telepen, China Post, Trioptic Code, Code128, GS1-128, ISBT 128,
Code 39, Code 39 Full ASCII, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar,
MSI(Plessey), Chinese 2 of 5, GS1 DataBar, Industrial 2 of 5, Standard 2 of 5
2-D:QR, DataMatrix, PDF417, Aztec, Hanxin etc.
Interfaces Supported: USB, RS232
User Environment
Operating Temperature: 0°C to 50°C
Storage Temperature: -40°to 70°C
Humidity: 0% to 95%, non-condensing
Shock Specifications: Designed to withstan d0.5mdrops
Drop Specification： Withstands 50 times 1.6m to concrete
Ambient Light Immunity: up to 100,000 Lux
