Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price

Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price thumbnail-1
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price thumbnail-2
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price thumbnail-3
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price thumbnail-4
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price thumbnail-5
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price photo-1
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price photo-2
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price photo-3
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price photo-4
Toilet Paper Making Machine, Model 787 -1092 -1575 Toilet Paper Machine Price photo-5
US$ 20000 - 88000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
yingfeng machine
Place of Origin:
China
Model Number:
787-1092-1575
Contact Supplier Request Quote Chat Now
Falong Paper Machinery And Equipment Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
tainjin/qingdao
Delivery Detail:
25 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name yingfeng machine
Place of Origin China
Model Number 787-1092-1575
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 1 year
Weight 5-25Tons of
Dimension(L*W*H) 75000mmx4000mm x 1800mm
Voltage 380v
Product Type Other, toilet paper machine
Condition New
Power(W) 45KW-120KW
Processing Type Other, toilet paper machine

                     Paper Product aking Machinery

Paper Product aking Machinery>> Model 787 -1092 -1575 toilet paper machine



Model 787 -1092 -1575 toilet paper machine

787-type toilet paper machine

Equipment technical parameters:

Products: toilet paper, napkin, book paper, culture paper, packaging paper, corrugated paper.

Raw material: original pulp, waste paper, bamboo, straw, cotton pole, etc

Clear paper width: 787mm

Equipment output: 800kg-1t/day

Production quantity: 13g -- 80g

Equipment speed: 40-- 90 m/min

Utility boiler: 0.5t high pressure boiler

Introduction to type 1092 toilet paper host:

Toilet paper, napkin, book paper, culture paper, packaging paper, corrugated paper.

Raw material: original pulp, waste paper, bamboo, straw, cotton pole, etc

Width of cleaning paper: 1092mm

Motor speed: 30 -- 100 m/min

M: 13 -- 120 grams per square

Productivity: 1 -- 3 tons per day

Mesh diameter: 100mm x 1450mm

Flange diameter: 1500mm x 1450mm

Model 1575 upside-down rotary screen toilet paper machine is mainly used for producing 16-30g /m2 toilet paper, all of which are corrugated toilet paper.
Main technical parameters:
Main product: toilet paper
Quantitative range: 16-30g /m2
Clear paper width: 1575mm
Production capacity: 3t-4t /D
Working speed: 100-120m/min
Design speed: 140m/min
Net width: 1950 mm
Gauge: 2400 mm
Transmission: segment transmission
Largest single weight: 12T

      Our factory is a high-tech enterprise which integrates the production and R&D of new-type papermaking machinery and pulping equipment. The main business now is: 787-1092-1575-1760-1880-2100-2400-2640-2880-3200-3600-4000-4750 single-cylinder, double-cylinder, multi-cylinder, long-net papermaking machine, circular net papermaking machine, cow Pulp and paper machine, culture paper machine, Xuan paper machine, carton hanging paper machine, packing corrugated paper machine, and small paper machine for small paper mills and family workshops, small environmental protection paper machine, toilet paper machine, burning paper machine, artillery paper machine, fire paper machine, yellow paper machine, etc. Various types of paper machines.

   Our factory has a complete set of pulping equipment: Dutch, Knife-Roller beater, high and low concentration hydraulic pulper, energy-saving pulper, high frequency vibrating screen, vacuum pump, pulp pump, pulp mixer, bamboo roughing mill, propeller, centrifugal screen, desander, processing various rolls and auxiliary equipment (toilet paper rewinder, punching pressure) Flower machine, toilet paper, burning paper cutting machine, etc. Papermaking equipment, calender, rewinder and paper cutter.

Sales manager: hao yingfeng +86-13603894288

Micro letter：13603894288

Email：940746614@qq.com

WhatsApp: 86-13603894288

imo: 86-13603894288

Email: 940746614@qq.com

Product Tags: Toilet Paper Machine , Paper Product Making Machinery , paper machine price , Model 787 toilet paper machine , Model 1092 toilet paper machine , Model 1575 toilet paper machine
