Help CenterModel 1575 Toilet Paper Machine, Corrugated Paper Machine
Related Products
-
New Type 2880 High Speed Toilet Paper Spraying MachineUS$ 100000 - 600000MOQ: 1 Set -
Type 787-1092 Small Toilet Paper MachineUS$ 20000 - 50000MOQ: 1 Set
-
1880mm High Speed Toilet Paper Machine, Corrugated Paper MachineUS$ 50000 - 150000MOQ: 1 Set
-
Model 1575 Toilet Paper MachineUS$ 50000 - 150000MOQ: 1 Set
-
787-type Toilet Paper MachineUS$ 20000 - 50000MOQ: 1 Set
This equipment has the different disposition may take the waste paper, the timber, the straw, the bamboo and so on as the raw material, through the processing produces the toilet paper, the packing paper, the box board paper, the writing paper, the firecracker paper and so on.
The following equipment is used for making toilet paper:
Technical parameters:
Products: toilet paper, paper, corrugated paper
Materials used: waste book paper, waste newspaper, waste paper edge, pulp board
Production quantity: 18--80g/m2
Working speed: 20-80 m/min
Width: 1575mm clear (maximum width: 1800mm)
Transmission: electromagnetic speed adjustment, open gear transmission
Supporting equipment:
Serial number equipment name quantity configuration power
1. Hydraulic deinking pulper 1 set 30KW
2. Vibration screen 1 4kw
3. Type 380 pulping machine 1 37kw
4. Rinsing machine 1 3kw
5. Model 700 thrusters 1 11kw
6. Centrifugal screen 1 7.5kw
7. 3 4kw 4-inch slurry pumps
8. Vertical mixer 2 sets 4kw
9. Model 1575 paper machine 1 18kw speed regulating motor
10. Rewinding puncher 1 4kw
11. One toilet paper cutter is 2.2kw
12. 1 vacuum pump
Auxiliary boiler:
1 1T boiler (provided by the customer or purchased by our company)
Production process:
Waste paper - shredder - shaker - grinding mill - well - rinsing machine (propeller is also here) - centrifugal screen - well - mill - paper machine net box - drying - winding - rewinding - paper cutting - hand packaging - product sales
Description:
1. If you need to produce folding napkins, you can change the rewinding perforator into a napkin folding machine to produce folded napkins.
2. When the motor and boiler on the equipment are not brought out of the factory, the customer can buy them locally, or they can be provided together by our company's purchasing agent. Please explain when purchasing agent is needed.
3. Different types of paper are produced and different raw materials are used. The specific equipment configuration may vary greatly and the price may vary.
Sales manager: hao yingfeng +86-13603894288
Email：940746614@qq.com
WhatsApp: 86-13603894288
imo: 86-13603894288
Email: 940746614@qq.com
Send Inquiry to This Supplier
