Help CenterComAp InteliNano NT MRS IN-NT MRS Gen-set Controller for Prime Power Applications
Related Products
-
ComAp IN-NT AMF InteliNano NT AMF Gen-set Controller for Single Gen-set Operating in Standby ApplicationsUS$ 188 - 199MOQ: 1 Pallet -
ComAp InteliNano NT Plus IN-NT PLUS Gen-set Controller for Prime Power or Stand-by ApplicationsUS$ 188 - 199MOQ: 1 Pallet
-
DSE8680 Synchronising Generator Bus Tie Control ModuleUS$ 188 - 199MOQ: 1 Pallet
-
DSE501K DSE520K DSE701 DSE702 Key Start Engine Control ModuleUS$ 188 - 199MOQ: 1 Pallet
-
DSE520R DSE521 DSE545 DSE548 DSE549 Manual Start Control ModuleUS$ 188 - 199MOQ: 1 Pallet
Controller for single gen-set operating in prime power applications
3 Phase generator voltage measurement
Connection type and voltage auto detect
Various generator and engine protections
Icon menu, no text
Automatic or manual GCB control
"Zero" power consumption mode
Battery voltage, Service time and Running hours indication
All setpoints and I/O's configurable via front panel
Light Tower mode supported
Event log (10 events)
Up to 3 analog inputs (shared with binary inputs)
COM terminal for analog measurement
Up to 6 binary inputs (1 binary input is shared with binary output)
2 high side - high current outputs
2 high side binary outputs
D+ pre-excitation terminal
ECU support (CAN J1939)
USB one-cord power supply and programing
License free PC configuration software (NanoEdit)
Standard cut-out dimension 96x96
Outside dimension 110x100
IP 65 (if optional gasket is used)
UL recognized
Send Inquiry to This Supplier
