Modular IACS Certified Engine Controller for Marine Applications
Control, monitoring and protection for any type of marine engines
Dedicated Emergency, Auxiliary, Harbour and Propulsion engines application
Single speed application for generators and variable speed application for propulsion, pumps, compressors
Support of wide range of EFI (ECU) engines with Tier 4F support
Support of multiple J1939 devices on one CAN bus line
Connection to engine via primary J1939 and backup J1587 buses or Cummins Modbus
Remote monitoring via Modbus, Ethernet and AirGate
Configurable Modbus RTU and Modbus TCP
RS232, RS485 via ID-COM, Ethernet communication support via IB-NT
WebSupervisor support for remote supervising and monitoring
Redundant architecture: Main unit + Backup module
Backup ID-RPU module with broken wire protections
Speed/load control via J1939 or J1587 buses
Symmetrical load sharing for propulsion engines with J1939 (via CAN bus)
Power management controller cooperation over CAN bus (IG/IS-NTC-BB)
Integrated clutch control
14 binary inputs
14 binary outputs
8 analog inputs
Marine certified extension modules for expandable number of Input/Outputs
80× AIN, 32× AOUT, 112× BIN, 112× BOUT
Load sharing for propulsion engines, Integrated clutch control for propulsion engines
Switching between primary and secondary battery
Internal configurable PLC with large set of functions
PLC lock capability to keep your know-how safe
Event driven History record up to 4000
Customizable colour HMIs, incuding InteliVision 12T OEM support
I-RD-CAN Marine remote display is replaced by ComAp HMIs InteliVision
Overview of ComAp marine approved products.
Existing HW version 1.0 is upgraded to HW version 2.0, ComAp is selling out of the stock existing HW version until 28th of February 2018.
From 1st of March 2018 is officially available only upgraded HW version 2.0.
Upgraded firmware ID-DCU-Marine-3.0.0 for upgraded controller HW version 2.0 is available in the installation suite and is NOT compatible with old controller HW version 1.0.1
Latest firmware for controller HW version 1.0.1 is ID-DCU-Marine-2.2.2, available in software download section below
