QZ-3 portable geological engineering drilling rig
- 100 Set / Sets per Month
- QingDao
- T/T L/C
- 9 days
- Adanced Electric Drills,Planers,Welding Machines,Pickaxes,Angle Grinder,Circular Saws,Marble Machine
- TPA DC/DC Converters power modules powered converter Convertisseur DC/DC abaisseur
- TPG DC/DC converters power supply module
- 20W 1.5KVDC Wide Voltage Input DC/DC Converters
- Power tools electric drill handheld machine
- Separated Hydraulic Down-the-hole Drilling Rig
Product Details
Brand Name: | HuaXia Master | Place of Origin: | China | Model Number: | QZ-3 |
Application: | drilling and geothermal drilling |
Product Description
1.The Brief Introductions of QZ-3 geological engineering drilling rig
The QZ-3 geological drilling rig is independently developed by Shandong Master Machinery Group Co.,Ltd., which is a portable multi-purpose drilling rig. The QZ-3 portable drill is equipped with a hoist, which is more convenient for geological drilling and lifting. It can do standard drilling hole, earth sampling and cone penetration with the heavy hammer.
The QZ-3 portable geological drilling rig uses diesel power, and it is more convenient to purchase oil. The rig is reasonable in design, advanced in structure, easy to assemble and disassemble, small in size, light in weight and easy to transport, which brings great convenience for field investigation and construction.
2. The Specifications of QZ-3 geological engineering drilling rig
QZ-3 portable geological engineering drilling rig | |
Borehole diameter (mm) | 46-110 |
Drilling depth(m) | soil Layer 110:15-20m lithosphere 91:20-25m lithosphere 75:25-30m lithosphere 60:30-40m lithosphere 46:40-50m |
Drilling pipe diameter (mm) | 30 |
Torque(n.m) | 180 |
Dimension(l*w*h) | 680*1200*3800(highly customizable) |
Weight(kg) | 165 |
3.Configuration List of QZ-3
Item | Specifications | Unit | Quantity | Remarks |
Base |
QZ-3 | pc | 1 |
Geological engineering drilling rig |
Winding engine | pc | 1 | ||
Drilling tower | pc | 2 | ||
Manual windlass | pc | 1 | ||
Diesel engine | pc | 1 | ||
Gear box | pc | 1 | ||
Drilling pipe including joint | 30*1000 | pc | 15 | Drill pipe |
Drilling pipe including joint | 30*2000 | pc | 5 | |
Reducing nipple | 58/38 | pc | 1 | 60mm core drill tool |
Core barrel | 58*800 | pc | 1 | |
Core barrel | 58*1500 | pc | 1 | |
Diamond bit | 60 | pc | 1 | |
Reducing nipple | 73/38 | pc | 1 | 75mm core drill tool |
Core barrel | 73*800 | pc | 1 | |
Diamond bit | 75 | pc | 1 | |
Safety clamp |
Tool | |||
Pipe wrench | ||||
Drill rod tong | ||||
Oil seal | pc | 2 | Vulnerable parts | |
Safety plate | pc | 1 |
if need high pressure pump and high pressure water pipes, please specify.
