CNC Double Sides Woodworking Glue Spreader Machine
US$ 5000 - 7000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
METRO
Place of Origin:
China
Model Number:
Single/Double side glude spreader
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
15 days
Related Products
-
Heavy Duty Woodworking Glue Spreader MachineUS$ 5000 - 6000MOQ: 1 Set -
Woodworking Single/ Double Surface Glue Spreader MachineUS$ 5000 - 6000MOQ: 1 Set
-
Heavy Duty Woodworking Glue Spreader MachineUS$ 5000 - 7000MOQ: 1 Set
-
Hydraulic Wood Veneer 8ft Spindle Rotary Peeling MachineUS$ 10000 - 20000MOQ: 1 Set
-
Automatic Wood Veneer Clipper MachineUS$ 2000 - 3000MOQ: 1 Set
Brand Name
METRO
Place of Origin
China
Model Number
Single/Double side glude spreader
Certification
CE, ISO, FDA
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
0ne year
Weight
1200kgs
Dimension(L*W*H)
2250*1250*1700MM
Condition
New
Voltage
380V
Power(W)
7.5kw
Type
Other, glue spreader machine
1.Main features:
1. Adopt the big diameter and high precision thick rollers: high rigidity, glue uniform.
2. Separately designed gears transmission box: Low noisy, work stable, long working life.
3. Start device specical designed for the rollers lifting and fasten: Safety, fast and convenient.
4. Roller speed and veneer out-put conveyor speed can be adjusted separately to meet different working requirements.
5. Emergency stop device to prevent any accidents.
2.Main technical specifications:
| Glue sprader machine model | BTJ-8QZ |
| Rubber spreadering rollers | Φ418mm x 2pcs |
| Metal squeezing rollers | Φ295mm x 2pcs |
| Rubber spreading rollers speed | 0-60rpm |
| Metal squeezing rollers speed | 0-17rpm |
| Veneer out-put conveyor speed | 0-90m/min |
| Glue spreader motor power | 7.5Kw |
| Veneer out-put conveyor motor power | 0.75Kw |
| Glue spreader machine overall dimension | 4500x2950x1850mm |
| Glue spreader weight | 5500Kgs |
