Ingke YKJD-8129NL 100% cross ARJC02-111008B Through Hole Tab Down 100 Base-T RJ45Network port connector
Part Number:ARJC02-111008B
Made in China:YKJD-8129NL
Original Manufacturer:Ingke Technology
Supply Ability:5500K-PCS/Month
Product Category:Modular Connectors / Ethernet Connectors
Packaging:Tray
Connector Type:RJ45
Number of Ports:1
Number of Rows:1
Applications:10/100 Base-T, AutoMDIX
Mounting Type:Through Hole
Orientation:90°Angle (Right)
Termination:Solder
LED Color:Yellow - Green
Number of Cores per Jack:4
Shielding:Shielded, EMI Finger
Features:Board Guide
Tab Direction:Down
Contact Material:Phosphor Bronze
Contact Finish:Gold
Operating Temperature:-40℃~85℃
Contact Finish Thickness:30µin (0.76µm)
Flammability Rating:UL 94 V-0
Shield Material:Copper Ally
Housing Material:Thermoplastic
Manufacturer: Ingke Technology Co.,Ltd
Our service:
1).Free sample is available!
2).OEM & ODM orders are welcomed.
3).We offer after-sale service for 8 years.
Our Advantage:
(1).OEM factory for Connector more than 10 years.
(2).Cost reduction, lead time within 1 week, FREE samples.
(3).After sales services 24*7 to help you solve any kind of problems
(4).Factory in central province of China, the products has been improved in Mechanical properties, electrical properties and environmental performance for 10-15%,moreover the price are more competitive for 5-10% over the market
(5).Main advantage products: 10G ICM and M8 connector(Vendor of ST and Qualcomm)
Ingke Technology Mass production of the following models;ARJ11D-MDSD-A-B-GLT2 ARJ14A-MESC-MU2 ARJ14A-MFSC-MU2 ARJ14A-MISD-MU2 ARJ14A-MFSA-MU2 ARJ14A-MESB-MU2 ARJ14A-MISA-MU2 ARJ14A-MFSD-MU2 ARJP11A-MBSB-A-B-EMU2 ARJP11B-MBSB-A-B-EMU2 ARJ11C-MASAB-B-A-2MU2 ARJ11B-ARJ14A-MASD-A-B-FMU2 ARJ14A-MBSD-A-B-FMU2 ARJC02-111008B ARJC02-111006K ARJC02-111006E ARJC01-111002T ARJ11B-MESBQ-A-B-EMU2 ARJ11C-MASAB-B-A-1MU2 ARJ11D-MDSD-A-B-FLT2 ARJ11B-MFSBQ-A-A-EMU2 MESCB-A-B-ELT2 ARJ14A-MASD-A-B-EMU2 ARJ11B-MBSCB-A-B-ELT2
