SY930 Mini Loader ,Europe Hot Sales，Front Shovel Type

Name: SY930 Mini Loader ,Europe Hot Sales，Front Shovel Type
Brand: SYNBON
SKU: 159055741
Availability: InStock

US$ 17685 - 19990 MOQ: 1 Piece

Key Specifications

Brand Name:

SYNBON

Place of Origin:

China

Model Number:

SY933

Synbon Machinery Co.,ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

30 days

Brand Name SYNBON

Place of Origin China

Model Number SY933

Type Front Loader

Certification 1years

After-sales Service Provided Engineers available to service machinery overseas

Warranty EPA4，CE,ISO9001

Condition New

Dimension(Long * Breadth * High) 6900×2280×3150 мм

Moving Type Wheel Loader

Rated Load 3000kg

SYNBON WHEEL LOADER SY930

Performance	1	rated loading	3000kg
	2	overall weight	7020kg
	3	bucket capacity	1.7m³
	4	maximum traction force	95KN
	5	maximum breakout force	127KN
	6	maximum grade ability	30℃
	7	maximum dump height	3250mm
	8	maximum dump reach	1006mm
	9	overall dimension (L×W×H)	6900×2280×3150 мм
	10	minimum turning radius	5097mm
Engine	11	model	Weichai Duetz
	12	type	Vertical, in-line, water cooled, 4-stroke diesel engine
	13	NO. of cylinder-bore*stroke	6-108*125
	14	rated power	92kw—2200r/min
	15	maximum torque	500N.m
	16	min. fuel-consume ratio	≦210Kw h
Transmission system	17	torque converter	YJ315-X
	18	gearbox mode	Power shaft normally engaged straight gear
	19	gears	4 forward 2 reverse
	20	maximum speed	40km/h
Drive axles	21	main reducing spiral	bevel gear grade 1reduction
	22	decelerating mode	Planetary reduction grade 1
	23	wheel base (mm)	2660mm
	24	wheel tread	1800mm
	25	ground clearance	400mm
Hydraulic system	26	system working pressure	16,5MPa
	27	boom lifting time	4.83
	28	total time	9.15±0.5s
Brake system	31	service brake	air assist disc brake on 4 wheels
Brake system	32	parking brake	Manual disk brake
Tyre	33	type specification	17.5-25
	34	front tyre pressure	0.4Mpa
	35	rear tyre pressure	0.35Mpa
