high quality robot use industrial metal mecanum wheel

CMA-40 Omni Wheel

• Product Description

• CMA series omni wheel provide 3100KG payload maximum ,while maintaining high accuracy. This wheel uses integrated molding process, maximizing the mechanical properties of materials. All the CMA series omni wheels use rolling bearings, polyurethane materials on the driven wheel surfacewith good performance in stability , quietness, durability and omni-direction. They are able to adapt to various indoor and outdoor occasions.

• Feature

• integrated molding process hub , high intensity ,high stiffnessRolling Bearingpayload between 0-3100KGindustrial-grade quality

• Detailed Images

• Diameter:	406.4mm	Wide:	219mm
  Wheels:	8	Bearing Type:	heavy duty Rolling Bearing
  Wheel Material:	Polyurethane	Hub Material:	steel
  Hub Surface Treatment:	High-Temperature Painting	Mount:	Flange
  Flange Plate Thinckness:	16mm	Flange Plate Diameter:	160mm
  Flange Cavity Inner diameter:	177mm	Typical Middle Hole Size:	70mm
  Weight:	53Kg	Load:	1600Kg
