Model:HTPV-15
Name:UV preconditioning Testing machine
Standard:According to IEC61215, IEC61646 standard requirement
Purpose:to precondition the module with ultra-violet (UV) radiation before the thermal cycle/humidity freeze tests to identify those materials and adhesive bonds that are susceptible to UV degradation
Technical specifications:
1、Use material:can completely obstruct ultraviolet rays,tightness,good thermal insulation’s high quality materials
2、Machine UV total irradiation area:more than 2000mm×2000mm,meanwhile satisfy 2 pcs module (2m×1m)
3、Light source life :system use metal halid lamp，lamp life is 1000 hours , delivery offer one set of spare part, use the life at above 2000 hours
4、Single lamp UVA and UVA relative energy rate:UVB approx occupy total energy 3%~10%
5、Irradiation strength:wavelength 280nm~385nm’s irradiation strength can reach about 100W/m²,promise the test cycle reduce as far as possible
6、Irradiance uniformity:be better than ±15％
7、Real-time monitor and show UVA and UVB strength
8、UVA (320nm~385nm), UVB(280~320nm) Each one of the fiber optic probes
9、Module surface temperature:60℃±5℃
10、Temperature resolution:0.1℃
11、Ozone: almost no ozone is produced
12、Light ways :upper light, module test plane vertical light source
13、Touch screen operate and real-time monitor , when reached the set value will automatic cut off the light source
14、Real-time figure show module surface temperature, measurement accurate±0.1℃
