Help CenterWet Leakage Current Testing Machine
Related Products
Model:HTPV-07A
Name: Wet Leakage Current Testing Machine
Standard:According to IEC61215 standard requirement
Purpose:
to evaluate the insulation of the module under wet operating conditions and verify that moisture from rain, fog, dew or melted snow does not enter the active parts of the module circuitry , where it might cause corrosion, a ground fault or a safety hazard
Technical specifications:
1、Test tank:size:2100×1000×250mm（W*D*H）,thickness 15mm, material:plexiglass
2、Temperature control :water constant temperature system researched and development by
HOTOTECH , temperature:22±3℃
3、Liquid resistivity:less than 3500Ω·cm
4、Spray system:nozzle adopt UL laboratory special nozzle , multi direction adjustment spray f the water pressure and flow amount can adjustable
5、Programmable insulation withstand voltage tester
5.1 Output voltage the maximum 0-5000V (adjustable)
5.2 Leakage current the maximum limit value:5mA
5.3 Output speed rate:500V/S
5.4 Insulation resistance test range:1MΩ～9999MΩ
5.5 Leakage current test range:0.001～5.000mA(DC)
6、Main configuration
6.1 Insulation withstand voltage tester
6.2 Water constant temperature system (control box)
6.3 Spray frame
6.4 Insulation water tank
6.5 conductivity meter
6.6 Sample frame
