Help CenterModule Breakage Testing Machine
US$ 1 - 2
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Hototech
Place of Origin:
China
Model Number:
HTPV-03
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
60 days
Related Products
Brand Name
Hototech
Place of Origin
China
Model Number
HTPV-03
Power
Electronic
Usage
Impact Testing Machine
Model:HTPV-03
Name: Module Breakage Testing machine
Standard:According to IEC61730-2004 standard requirement
Purpose:
This test is provide confidence that cutting or piercing injuries can be minimized if the module is broken
Technical specifications:
1、Impact height:300mm～1220mm
2、Device test frame
2.1、The inner dimension of test sample: according to customer’s pv module size requirement
2.2、Sample frame material :channel width ≧100mm, thickness 3mm
2.3、Installation the protection device at the both of side
3、Impactor
3.1、The mass of impactor:45.5 ± 0.5kg
3.2、Inner filling diameter 2.5-3.0mm’s pellets
