Help CenterXYC-200 China Manufactures Small Core Borehole Deep Water Well Mining Drilling Rig Machine
Related Products
-
XYC-200A Tricycle Hydraulic Rotary Drilling Rig Water Well Drilling Rig Machine for SaleUS$ 4500 - 5000MOQ: 1 Set -
XY-100 Hydraulic Core Drilling RigUS$ 4500 - 5000MOQ: 1 Set
-
XY-150 Hydraulic Core Drilling RigUS$ 4500 - 5000MOQ: 1 Set
-
XY-180 Hydraulic Core Drilling RigUS$ 4500 - 5000MOQ: 1 Set
-
XY-200 Hydraulic Drilling Machine in Drilling MachineUS$ 4500 - 5000MOQ: 1 Set
1. Characteristic of XYC-200 vehicular drilling rig
a.XYC-200 is a multi-function hydraulic vehicle mounted rotary spindel drilling rig.
b.The Tang Jun automobile chassis chassis, transmission system and rig winch, mud pump and other important accessories installed in the chassis, layout is reasonable and compact, easy to operate.
c.It configures BW160 mud pump, high pressure, big flow, which can ensure drilling depth and diameter.
d.The rig has shifting device, it can move on the vehicle, convenient to operate while drilling.
e.The hydraulic folding mast is safe and convenient to operate.
Adaptability range of XYC-200 vehicle type drilling rig,Geological survey and exploration, road and high-rise building foundation exploration, and all kinds of concrete structure inspection holes, river embankments, subgrade grouting holes, drilling and direct grouting, civil wells and ground temperature central air conditioners.
2. Parameters of XYC-200 vehicular drilling rig
Parameters | ||||
Drilling depth(m) |
30-200 |
|||
Drilling diameter(mm) |
300-75 |
|||
Drilling Angel(mm) |
90-75 |
|||
Spindle rotating speed(r/min) |
64/128/287/557 |
|||
Spindle stroke(mm) |
450 |
|||
Main hoisting capacity(single line)(Kg) |
1600 |
|||
Main hoisting line capacity(m) |
35 |
|||
Hoisting speed(r/s) |
17/35/75/151 |
|||
Wireline diameter(mm) |
12.5 |
|||
Mast height(mm) |
7000 |
|||
Mast effective height(mm) |
6500 |
|||
Kelly/active pipe(mm) |
59*53 |
|||
Drill rod(mm) |
42/50/60 |
|||
Drill rig weight(kg) |
1150 |
|||
Power Unit |
Model |
ZS1115 diesel engine |
||
Rated power |
14.7kw/2200rpm |
|||
|
BW-160 mud pump |
Rated flow(L/min) |
160 |
||
Rated pressure(Mpa) |
1.3 |
|||
Driving power(kw) |
5.15 |
|||
main machine weight(kg) |
190 |
|||
Dimension(mm) |
1110*725*965 |
|||
|
Chassis
|
Model |
95Hp light truck The 3.3 meter steeplechase double light card |
||
Drive mode |
4*2 |
|||
|
Power unit |
Model |
Quanchai 4B2-95C40 |
||
Emission standard |
GB3847-2005,GB17691-2005Ⅳ |
|||
Rated power(KW) |
70 |
|||
Rotating speed(r/min) |
3200 |
|||
Shandong Master Machinery Group Co.,Ltd.
Sales manager：Candice
Mobile phone：8618865479502
WeChat: 18865479502
QQ：1447852867
Service hotline：400-167-0537
TEL：0537-3860909
Website：
