LF18 Digital Anemometer Portable handheld vane air speed meter
Features:
High accuracy
Small size
Antiskid side
Six pieces vane wheels
NTC thermometer for air temperature measurement
*Measurement items: Air velocity, Air temperature
*Measurement range:
----Air speed: 0~30m/s, 0~90km/h, 0~5860ft/min, 0~55knots, 0~65mph (± 5%)
----Air temperature: -10~45º C, 14~113º F (± 2º C)
Beaufort scale
*Display: LCD.
it can display air speed and air temperature at the same time.
*Sensor:
----Air speed sensor: Plastic impeller, magnetic induction
----Temperature sensor: NTC thermometer
*Low battery indication: Yes
low temperature indication: yes
*Auto power shut off: 14 minutes without any operation
*Backlight: 12 seconds active by press any key
*MAX/MIN/AVG reading
Specifications |
Range |
Resolution |
Min starting point |
Accuracy |
Air speed |
0-30 m/s |
0.1 |
0.1 |
5% |
0-5860 ft/min |
19 |
39 |
||
0-55 knots |
0.2 |
0.1 |
||
0-90 km/h |
0.3 |
0.3 |
||
0-65 mph |
0.2 |
0.2 |
||
Air temperature |
-10~45º C |
0.2 |
± 2º C |
|
14~113º F |
0.36 |
3.6F |
||
Battery |
9V |
|||
Temperature sensor: |
NTC thermometer |
|||
Air speed sensor: |
Plastic impeller, magnetic induction |
|||
Operate temp: |
-10~45º C , 14~113º F |
|||
Storage temp: |
-40~60º C , -40~140º F |
|||
Operate humidity: |
Less than 90%RH |
|||
Current consumption: |
3 mA |
|||
Weight: |
60g |
|||
Dimensions |
52.5*35.5*160mm |
|||
Application:
Outdoor project air velocity test
Indoor air conditioner air velocity test
Computer host air velocity test
Air fan air velocity test
Air vehicle
Offshore
Environment protect
Air conditioning system
