Rotary Disk Sorting Machine for Long Screws

Rotary Disk Sorting Machine for Long Screws thumbnail-1
Rotary Disk Sorting Machine for Long Screws thumbnail-2
Rotary Disk Sorting Machine for Long Screws thumbnail-3
Rotary Disk Sorting Machine for Long Screws thumbnail-4
Rotary Disk Sorting Machine for Long Screws thumbnail-5
Rotary Disk Sorting Machine for Long Screws photo-1
Rotary Disk Sorting Machine for Long Screws photo-2
Rotary Disk Sorting Machine for Long Screws photo-3
Rotary Disk Sorting Machine for Long Screws photo-4
Rotary Disk Sorting Machine for Long Screws photo-5
US$ 50000 - 100000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Eyason
Place of Origin:
China
Model Number:
EY-02
Contact Supplier Request Quote Chat Now
Zhejiang Eyason Intelligent Technology Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Eyason
Place of Origin China
Model Number EY-02

　

Feature:

For M8~M16 screws and bolts, under head length 125~250mm

Available for 2~7 cameras

Optional: wheel crack checking system (LS-1501) for head crack inspection

Optional: Bending checking module

Optional: 360∘rotation module for thread damage inspection

Optional: two kinds of Eddy current systems:

 1. For head open crack inspection

 2. Material mix-up or with/without heat-treatment



Sorting items:

• Screw-head height, width • Recess depth • Pinhole Excess Material

• Ineffective thread length  • Minor Thread Diameter • Feature Angle

• Major Thread Diameter  • Pitch Distance • Feature No.

• Bevel Thread • Screw Length • Feature Similarity

• Cone Point • Zinc:Yes or No（Head Top View） • Feature Length

• Pinhole Alignment • Head Crack • AF/AC

• Head Mark • Roundness • Material Mix-up

Inner Roundness • Inner Concentricity • Broken pin

• Inner Excess Material • Shorten AF • Deformed Thread

• Feature-Center Distance



Optional Function:

• Bottom Sorting

• 360° Thread Damage • Head Wheel Crack • Screw Bending (Multi-Images)



Specifications:

• Wire Diameter:φ8~16mm • Head Width:φ10~35mm

• Length Under Head:60~250mm • Sorting Precision:±1pixel

• Head Height: 5~30mm •Sorting Speed:60~100/PPM




Product Tags: Larger fastener visual sorting machine , Piston optical sorting machine , Fastener optical sorting machine
