HG911 is a mini GPON optical network terminal device , which applies to pure broadband access.It adopts mini-type compact structure design with high-integration and can provide 1 GE（RJ45）interfaces. Supports the technology of layer 3 router function with PPPOE/DHCP/Static IP,and it’s easy to maintenance and manage.It can be applied to FTTH/FTTP access application for resident and business Users. and it is fully compliant to technical regulations such as ITU-TG.984.x technical requirment of GPON Equipment.Remote service distribution, fault diagnosis and performance statistics can be realized by OMCI, which effectively reduce the operation and maintenance cost.
Technical items | Description |
Optical property | |
Upstream PON interface | 1 GPON interface, SC single-mode/single-fibre, uplink 1.25Gbps, downlink 2.5Gbps |
Wavelength | Tx 1310nm, Rx 1490nm |
Optical output power | -1~+4dBm |
Receiving sensitivity | <-28dBm |
Farthest distance | 20km between OLT and ONU |
Optical interface | SC/UPC connector |
Downstream LAN interface | 1*10/100/1000Mbps auto adaptive Ethernet interfaces, Full Duplex/Half Duplex, RJ45 connectors |
Ethernet function | Support IEEE802.1Q VLAN |
Support speed rate inhibition of broadcast packet at ONU | |
IEEE 802.3X flow control | |
Support 16 multicast addresses at each LAN port | |
Security strategy | Support AES-128,data encryption for both upstream and downstream Support dynamic update of key
|
Management maintenance | Centralized OLT management based on OMCI |
WEB，CLI | |
Upgrade software remotely | |
Hardware information | |
Indicators | 4 indicators, for status of power supply, PON port and 1 Giga-Ethernet port. |
DC power supply | +12V, external AC-DC power adaptor |
Power consumption | ≤2.5W |
Operating condition | Operating temp: -5~+55℃ |
Storing condition | Storing temp: -30~+60℃ |
Dimension | 100mm*87mm*25mm(length*width*height) |
Net weight | 0.24Kg |
