Alcatel Lucent Bell I-240E ONU FTTH ONT GPON ONU 4GE/FE+2 POTS Alcatel I-040E I-240E I-120E-Q
Features
- GPON features
Class B+ optical module.
Security authentication mode: SN, password or SN+password.
Upstream/downstream FEC.
- Voice features
SIP and H.248 protocols.
Media stream and signaling stream separation.
- Multicast features
IGMP V2&V3 snooping/IGMP proxy.
- Wi-Fi features
80211b/g/n, certified by the Wi-Fi Alliance.
- CATV feature
Remotely CATV port enabling/disabling and remotely query of the CATV port status.
- Routing features
NAT function.
Internet, IPTV and VoIP services are automatically bound to ONT ports.
Virtual server, port trigger, DMZ, and DDNS.
- Maintenance features
Local management using Web and remote management using TR069 and OMCI.
Optical power monitoring.
802.1ag Ethernet OAM.
Loop-line test of POTS ports, call emulation and PPPoE dialup emulation.
- Reliability features
Dual systems for software protection.
Type B protection and rogue ONT detection.
Lithium battery backup and backup battery monitoring.
- Greenengery-saving features
Dynamic power consumption adjustment.
With a backup battery, the guaranteed services can be selected flexibly.
Specifications
Dimensions(W x D x H)268 mm × 213 mm × 34 mm
Port:4POTS + 4GE + 1USB + 1CATV + 1Wi-Fi
Average power consumption13.5 W
Operating environmentTemperature: 0°C~+40°C;
Humidity: 5%–95%, non-condensing
Power supplyAdapter input: 100–240 V AC, 50–60Hz;
Adapter output: 11–14 V DC, 2 A
WeightAbout 800g (including the power adapter)
Deployment Scenarios
Plug-and-play (PnP): Internet, IPTV and VoIP services can be deployed by one click on the NMS and on-site configuration is not required.
Remote diagnosis: Remote fault locating is implemented by the loop-line test of POTS ports, call emulation and PPPoE dialup emulation initiated by the NMS.
Link monitoring: E2E link detection is achieved using 802.1ag Ethernet OAM.
High speed forwarding: GE line rate forwarding in the bridge scenario and 900 Mbit/s
forwarding in the NAT scenario.
Green energy-saving: 25% power consumption is saved with highly integrated system on chipset (SOC) solution, in which, a single chip integrates with PON, voice, gateway and LSW modules.
About the Distribution:
As a golden distributor of HUAWEI, all of HUAWEI prodcucts from Polytrade/Sandes Technology are 100 % Original and Brandnew unless per clients’ requests; customers could claim 10time cost if you find we offer used or fake products. We offer one year warranty for all on-display products.
The HUAWEI products by us are whole series of hot-sell products, and if you did not find what you need on alibaba web, please contact us via sales[at] to gain supports.
Products Photos:
