CNC metal engraving and milling machine for surface carving
a. Whole parts use GB-HT300 resin sand casting component, by tempering and natual aging to eliminate internal stress.
b. Built-in counterweight : counterweight with guide rod, won't be shaking when moving up and down.
c. The sliding surface is with automatic lubrication pump device, to ensure the service life of the machine.
d. Sealed sheet metal and excretion inside the machine.
e. Urgent stop button in set on the machine body, it is for easy. It is convenient installing and regulating.
Main Specification And Technical Parameters
| Description | Unit | Vertical | Horizontal |
| X-Axis Travel | mm | 350 | 200 |
| Y-Axis Travel | mm | 430 | 300 |
| Z-Axis Travel | mm | 300 | 200 |
| Spindle Nose To Table Distance | mm | 390 | 150 |
| Table Size | mm | 1850 x 420 | 1440 x 235 |
| T-Slot (Slot Number *W* Spacing) | mm | 3x14 x 100 | / |
| Maximum Load | kg | 500 | 500 |
| Spindle Taper | ER20 | ER20 | |
| Spindle Speed | rpm | 24000 | 24000 |
| Fast Delivery X,Y,Z Axis | m/min | 36 | 24 |
| Spindle Motor | kw | 3 | 3 |
| X,Y Axis Motor | kw | 1.5 | 1.5 |
| Z Axis Motor | KW | 1.8 | 1.8 |
| Magazine Type and Number of Tools | pc | 8 | 8 |
| Positioning Accuracy ( JIS Standard ) | mm | ±0.005/300mm | ±0.005/300mm |
| Repeatability Accuracy ( JIS Standard ) | mm | ±0.01 | ±0.01 |
| Machine Weight (Approx.) | kg | 4200 | 2400 |
| Machine Size (L*W*H) | mm | 2900x2000x2300 | 2500x1600x1900 |
| Air Requirements | kg/cm2 | 6 | 6 |
Remarks : some parameters can be customised by client's requirement.
Photos Of Machine
Machine Application Fields
It is widely used in machining brass,copper,aluminum alloy,like valves,sanitaryware,door hardware,household appliances,auto parts ect..High quality with compotitive price and good appearance.
For CNC metal engraving machine :
1,Before the shipment, we will spray anti-rust oil on the machine's surface .
2,Then use the plastic film packaging to prevent moisture and rust.
3,Finally, put the machine in wooden cases, use solid seaworthy wood box package with steel belt, it will be save space as much as possible for container loading.
Before payment
Free contact for the most suitable machine.
Free professional design for each customer especially.
After sale service
24 hours technical support by phone, email, skype ,whatapp or wechat.
1years warranty period
Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.
By offering this support, we make sure the customer start the business smoothly, to realize win-win cooperation.
Payment
L/C, 30% deposit by T/T,70% spare payment L/C.
T/T, 30% deposit by T/T,70% spare payment before shipment.
1. Company Profile
Ancon Automatic Machinery belongs to the subsidiary company of Nanan Delin Machinery Manufacturing Co.,Ltd. It Locates in China well-known sanitaryware hometown-Nanan.
Our company was established in 1998. The products spread all over domestic market, as well as nearly twenty countries. In Inara, Iran, Uietnam and other internatioanl exhibition booth. Meanwhile it has enlarged many sales and aftersale service centers. And a top-level talents team are ready for service at any time, and this promises all kinds of customers' problems can be dealt promptly.
