Specifications
Axis CNS Polishing and Buffing Machine1.high speed
2.efficient
3.high quality
1. Axis CNS Polishing and Buffing Machine Function:
Axis CNS Polishing and Buffing Machine Functions
1. The machine equips with 6 NC axes, can finish the polishing and buffing of 4 work pieces in one time.
2. 4 NC axes polishing and buff simultaneously.
3. Handhold programming demonstrator.
4. Able to over programming.
5. Full auto, waxing system.
The other kinds
1.Suit for polishing hardware applications,sanitary,industry,and small bent pipe,etc.
2.the spindle can assemble the rubber,cloth,hemp,and sand wheel and sang belt of diameter ≤ 350mm,breadth ≤ 75mm.
3.It can be converted into the YD-010-type sand belt polishing machine
4.Aluminum Core rubber wheel:Outside diameter 300mm x inside diameter 26mm x breadth 50mm.
5.Sand delt spec:length 2100mm(2400mm)(3200mm) x breadth 50mm
Rotary Index Table Automatic Polishing Machine Function
1. SIMENS PLC with high capablity has been adopted, human-equipment interface, electric parts with international brand such as ABB, EMERSON, SCHNEIDER, the equipment comply with CE stand arid environment free requirement.
2. Double group operation program have been adopted which can polish two different products with precision while the equipment can switch automatically.
3. Precision angle polishing program has been adopted which can enhance precision polishing degree on the complex part of the products through programming on setting precision polishing angle.
4. Revolving operation table with four stations has been adopted which can precision polishing up to four products at the same time. The jigs are simple with low cost and are easy for changing which is more suitable for the production moudle of various series and kinds.
5. Nested precise polishing way has been adopted for precise polishing on overall parts of products.
6. Precise polishing can be used directly after 400 coarse polishing which can decrease procedure during coarse polishing and expense.
7. The equipment is suitable for percise polishing on different metal material(Brass, Aluminum, Zinc Alloy atainless, etc.).
8. The equipment is suitable for precise polishing on products with different shape(various kinds of faucet body, handle wheel, round pipe, different kinds of decoration parts, etc.).
9. The operation for the equipment is simple which has low requirement on the ability of the operator which can increase production efficiency, decrease work intensity while save production cost at the same time
2. Axis CNS Polishing and Buffing Machine certification:
3. Axis CNS Polishing and Buffing Machine product:
1. Four working stations work simultaneously, and with one time programming, the machine can finish the polishing and buffing jobs of four workpieces in one time
2. The machine has 6 free degree, to achieve all dimensions curved surface working
Fast fixtures changing structure
Fully Automatic Waxing System
| Finish the polishing/buffing jobs in any angle and position |
4.our factory
5.our services
1.Reply your enquiry in 24 working hours.
2.Experienced staffs answer all your qyestions in professional and fluent english.
3.Customized design is availlable.
4.Exdusive and unique solution can be provided to our customer,by your our well-trained and professional engineers and staffs.
5.Special discount and protection of sales area provided to your distributor.
Our factory estabilish in 1995 ,the quality is certificated by CE.
