IRC57, is a low cost, M2M, data logger, Lora Engine which can transmit and receive analog, digital and pulse counter data, PLC, Varity metering equipment to Lora gateway network to monitor pressure, temperature, flow, accelerate, humidity sensor and so on.
> Battery supply
> can emission up to 10,000 meter
> Can set freely by software
> very low consumption
> Supports Modbus RTU protocols;
> 2 RS232 Serial Ports, and 1 RS485 Serial Ports;
> UP TO 3 Analogue Inputs. (12 bit resolution, 0-5V or 4-20mA can be programmer by switches);
>UP TO 3 Digital Relay Outputs :120VAC/3A, 24VDC /3A, Can be controlled by Event, scheme, Incoming call, SMS Commands, Timer, Interlock; 2 outputs can setup as NC or NO type;
> User friendly PC Programming Interface, it can remotely program the terminals as well as to upload the data from the terminals by SMS or GPRS, all of the Current Value or status of the terminal can be display directly, and also will display the SMS Command details while you programming it;
DC Power supply |
9-15V DC/ battery suplly |
Power consumption |
100uA |
Emission range |
Up to 10Km |
Frequency |
433MHZ,470MHZ,868MHZ,915MHZ,910MHZ, |
Antenna |
50 Ω SMA Antenna interface |
Serial |
RS485 |
Temperature range |
-30°C ~ +70 °C |
Humidity range |
Relative humidity 95% |
Digital Input |
6 digital inputs(Dry contact) |
output |
4 drivable relay outputs(open-collector outputs) |
Output drive voltage |
Equal to input DC voltage |
Output drive power |
Drive voltage ≤35V, drive current ≤500mA |
Analog Input |
4 analog inputs(4~20mA or 0~5V) |
Audio interface |
3.5mm audio in and audio out |
Exterior dimension |
130×80×25mm |
Weight |
370 g |
