LANPAI Multi Lines P10 Outdoor Advertisement World Market White Flexible Led Screen
| Led screen Technical parameter | ||
| Unit board | Pixel pitch | 10mm |
| Module size | 320mm*160mm | |
| Resolution of module | 32*16dots | |
| Density of pixel | 10000dots/m2 | |
| Pixel configuration | LED546 1W (Red, Amber, Yellow, Green, White) | |
| Main Technical parameter | Red wavelength | 625±2nm |
| Green wavelength | 525±2nm | |
| Blue wavelength | 470±2nm | |
| Colors | 16777216 | |
| Best viewing distance | 10-300m | |
| Horizontal/Vertical Viewing angle | 120 degree/60 degree | |
| Gray scale | 16bits per color | |
| Color temperature | 6500k | |
| Brightness | More than 4000cd/sqm | |
| IP grade | Front :IP67 back: IP65 | |
| Frame frequency | 60HZ | |
| Refresh frequency | ≥2000HZ | |
| Control method | Synchronization/Asynchronization | |
| Drive method | 1/4 Scan | |
| Temperature | Storage:-40°C-+85°C | |
| Working:-40°C-+65°C | ||
| Operating ambient humidity | 10%—95%RH | |
| Earth leakage current | < 2mA | |
| Defects rate. | ≤0.00001(Led display line standard<0.0001) | |
| Flatness | Tolerance of interpixel ≤0.3mm | |
| Tolerance of modules clearance ≤0.6mm | ||
| MTBF | More than 10,000 hours | |
| Life span | More than 100,000hours | |
| Power | Operating voltage | AC110V/220V±10% |
| Maximum/Average power consumption | 1100/600w/m2 | |
| Current | ≤20mA(single LED) | |
| Power switch | Automatic switch | |
| Control system | CPU | Pentium4 or above |
| Signal Input | Composite ,S-video,Component,VGA,DVI,HDMI,SDI,HD_SDI,etc | |
| Controlling system | main controller card+optical fiber transmission | |
| Control method | Asynchronization | |
| Systems operating platforms | WinXP,Win2000,Vista, Win7 etc. | |
Usage
Service propaganda in finances, post offices, telecom, commerce, hospitals, sports stadiums
Policies and decrees issued from government organizations
Instructions, guidance and information issuance in airports and railways.
Comercial advertising LED display screen, bank&stock exchange LED display screen for rates showing, train & bus station.
Technical features
1.Preeminent effects: Clear and stable pictures without distortion and disturbance.
2.High quality: adopting first-class chips and wafers imported from abroad
3.Flexible form: continuity, overlying, combination of dynamic and static playing, various effects include rolling moving, typewriting, gradual changing and so on
4.off-line running function: adopting the monolithic design technology and computer string communication way, which can operate in off-line state setting the dates and revising a data via the RS232 cable or Network cable
Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.OEM&ODM,any your customized lightings we can help you to design and put into product
3.Protection of your sales area,ideas of design and all your private information
4.Top Quality+Reasonable Price+Responsible After Service=Successful & Win
5.Produce all kinds of Pitch: P4.75, P7.62, P10, P12, P16, P20, P25, P31.25...
Product show:
Click on the image below to see more products.
Shenzhen Panels Elec.Co.,Ltd.
Established 2006 , is a professional LED display manufacturing company with a 2,000-square-meter factory. It's only 25 minutes away from Shenzhen internation airport.
We are proud to announce that we are a pioneer and front runner in the fields of LED badges, LED mini display and LED moving signs in the world.
Our main products are: LED name badge,LED Desktop sign,LED indoor and outdoor LED moving sign,LED control card etc.
1.We accept DHL, UPS, FEDEX, EMS, TNT, by sea, by air flight and so on. If you like other shipping ways please contact us .
2.We will send goods that in stock within 3 working days, and custom product within 5-15 days according the order quantity.
3.Please note DHL/UPS/FEDEX usually takes about 3-5 days, and EMS/TNT usually takes about 5-8 days, By boat it need 3-45 days (It depends on our sea port on your country)
4.The buyer are responsible for any insurance, problems, damage which caused by shipping service such as accidents, delay, or other issues. Besides the buyer should be responsible for any tax or duty charge by your own country.
Q: Do you accept customize size?
A: Yes, of cause. Just tell us your request, we will do the suitable one to you.
Q: What is the led chip packing?
A:Indoor:SMD 3528/2121/1010; Outdoor:546 oval lamp/346 oval lamp.
Q:Why Choose us?
-We are Alibaba Assessed Gold Supplier
-More professional, best service
-100% QC inspection before shippment.
-We are direct factory manufacturer for led display, so quick delivery is no problem.
