Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1

Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 thumbnail-1
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 thumbnail-2
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 thumbnail-3
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 thumbnail-4
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 thumbnail-5
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 photo-1
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 photo-2
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 photo-3
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 photo-4
Eco-friendly Insulation Customized Design Color Heat Shrink Tube Shrink Ratio 2:1 photo-5
US$ 0.08 - 1.5 MOQ: 1 Meter
Key Specifications
Get Latest Price
Brand Name:
LDDQ
Place of Origin:
China
Model Number:
DRS-2
Contact Supplier Request Quote Chat Now
Zhejiang Langdao Electgric Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo
Delivery Detail:
10 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name LDDQ
Place of Origin China
Model Number DRS-2
Material PE
Type Insulation Sleeving
Application Low Voltage
Rated Voltage 600-1000v
Tensile Strength ≥10.4MPa

Name: Low voltage flame retardant heat shrink tube

Specification: Radial shrinkage ratio ≥50%

Longitudinal shrinking ratio≤5%

Work Temperature: Suit temperature: -55℃～125℃

The lowest shrink temperature: 70°C

Complete shrink temperature:110°C

General complete shrink temperature: 120°C

Work Voltage: less than 1KV

Color: red, green, yellow, blue, black, white, transparent

Characteristic; good insulation, soft and elastic, low shrink temperature, and fast shrink, convenient to use, heating by the alcohol lamp or heat gun.

Specification: Φ1.0mm-Φ200mm

Type

Inner diameter before shrinking

Inner diameter after shrinking

wall thickness before shrinking

wall thickness after shrinking

Available Range

Packing Length

(mm)

(mm)

(mm）

(mm)

(mm)

(m/roll)

1.0/0.5

≥1.3

≤0.05

0.18±0.02

0.36±0.02

0.5--0.9

200

1.5/0.75

≥1.8

≤0.75

0.18±0.02

0.36±0.02

0.75--1.4

200

2.0/1.0

≥2.3

≤1.0

0.2±0.02

0.4±0.02

1.0--1.8

200

2.5/1.25

≥2.8

≤1.2

0.2±0.02

0.4±0.02

1.25--2.3

200

3.0/1.5

≥3.3

≤1.5

0.22±0.02

0.44±0.02

1.5--2.7

200

3.5/1.75

≥3.8

≤1.75

0.22±0.02

0.44±0.02

1.5--2.7

200

4.0/2.0

≥4.3

≤2.0

0.25±0.02

0.5±0.02

2.0--3.6

200

5.0/2.5

≥5.3

≤2.5

0.25±0.02

0.5±0.02

2.5--4.5

100

6.0/3.0

≥6.3

≤3.0

0.25±0.02

0.5±0.02

3.0--5.4

100

7.0/3.5

≥7.5

≤3.5

0.3±0.05

0.6±0.05

3.5--6.3

100

8.0/4.0

≥8.5

≤4.0

0.3±0.05

0.6±0.05

4.0--7.2

100

9.0/4.5

≥9.5

≤4.5

0.3±0.05

0.6±0.05

4.5--8

100

10/5.0

≥10.5

≤5.0

0.35±0.05

0.7±0.05

5.0--9

100

12/6.0

≥12.5

≤6.0

0.35±0.05

0.7±0.05

6.0--10

100

14/7.0

≥14.5

≤7.0

0.35±0.05

0.7±0.05

7.0--13

100

16/8.0

≥17

≤8.0

0.4±0.05

0.8±0.05

8.0--15

100

18/9.0

≥19

≤9.0

0.4±0.05

0.8±0.05

9.0--17

50

20/10

≥21

≤10

0.4±0.05

0.8±0.05

10--19

50

22/21

≥23

≤11

0.4±0.05

0.8±0.05

11--21

50

25/12.5

≥26

≤12.5

0.4±0.05

0.8±0.05

12.5--24

50

28/14

≥29

≤14

0.4±0.05

0.8±0.05

14--27

25

30/15

≥31

≤15

0.45±0.05

0.9±0.05

15--29

25

35/17.5

≥36

≤17.5

0.45±0.05

0.9±0.05

17.5--34

25

40/20

≥41

≤20

0.5±0.05

1.0±0.05

20--39

25

50/25

≥51

≤25

0.5±0.05

1.0±0.05

25--49

25

60/30

≥61

≤30

0.5±0.05

1.0±0.05

30--59

25

70/35

≥71

≤35

0.5±0.05

1.0±0.05

35--69

25

80/40

≥81

≤40

0.55±0.05

1.1±0.05

40--79

25

90/45

≥91

≤45

0.55±0.05

1.1±0.05

45--89

25

100/50

≥101

≤50

0.6±0.05

1.2±0.05

50--99

25

120/60

≥121

≤60

0.6±0.05

1.2±0.05

60-119

25

150/75

≥151

≤75

0.65±0.05

1.3±0.05

75--149

25

180/90

≥181

≤90

0.65±0.05

1.3±0.05

90--179

25

200/100

≥201

≤100

0.65±0.05

1.3±0.05

100--199

25

Product Display

Our Service
1.Free Samples

We can offer free samples, if you pay for shipping fees.

2.OEM/ODM

We can change the lable according your design.

3.After-sales Service

Best after-sales service. We provide detail packing photos and good communication during whole production.


FAQ
Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: The shippment will be arranged within 1 week for the stock products,or others will be arranged in 15- 20day after the payment confirmed according to the order QTY.

Q: Do you provide samples ? is it free or extra ?

A: Yes, the sample is free, would you mind bear the freight cost?

Q: What is your terms of payment ?

A: Payment

Contact :

Email: killy@cnlddq.com/lddq@cnlddq.com

Tel: 86 180 8661 1078

Wechat: 86 180 8661 1078

Skype: ljj0926


Product Tags: heat shrink tube Shrink ratio 2:1 , insulation heat shrink tube , Eco-friendly heat shrink tube
