Product Details
Brand Name: | CKANER | Place of Origin: | China | Model Number: | 1400G |
Type: | Barcode Scanner | Interface Type: | USB | Products Status: | Stock |
Colour Depth: | 32 Bit | Max Paper Size: | OTHER | Scan Speed: | 100+-10 times/sec |
Optical Resolution: | 5mil | Scan Element Type: | CCD |
Product Description
Ckaner 2018 Area-Imaging qr code scanner HY 1400g 2d barcode scanner
Mechanical
Dimensions (LxWxH) 43 mm x 180 mm x 66 mm
Weight 119 g (4.2 oz)
Electrical
Input Voltage 4.0 to 5.5 VDC
Operating Power 2 W (400mA @ 5 VDC)
Standby Power 0.45 W (90mA @ 5 VDC)
Host System Interfaces USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Humidity 0% to 95% relative humidity, non-condensing
Drop Designed to withstand 30 1.5 m (5") drops to concrete
Environmental Sealing IP42
Light Levels 0 to 100,000 lux (9,290 foot-candles)
Scan Performance
Scan Pattern Area Image (640 x 480 pixel array)
Motion Tolerance Up to 10 cm/s (4 in/s) for 13 mil UPC at optimal focus
Scan Angle Horizontal 42.4°; Vertical: 30.8°
Symbol Contrast 35% minimum reflectance difference
Pitch, Skew 60°, 70°
Decode Capability
1400g1D: all standard 1D symbologies
1400gPDF: all standard 1D and PDF417 symbologies
1400g2D: all standard 1D, PDF417 and 2D symbologies
