Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Zebra GK420d Direct Thermal Label Printer

Zebra GK420d Direct Thermal Label Printer

Name: Zebra GK420d Direct Thermal Label Printer
Brand: CKANER
SKU: 158336870
Availability: InStock

Zebra GK420d Direct Thermal Label Printer thumbnail-1

Zebra GK420d Direct Thermal Label Printer photo-1

US$ 628 - 888 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

CKANER

Place of Origin:

China

Model Number:

GK420D

Contact Supplier Request Quote Chat Now

CHONGQING CKANER TECH.Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou shenzhen shanghai

Delivery Detail:

5 days

Product Details
Company Profile
Contact Us

Brand Name CKANER

Place of Origin China

Model Number GK420D

Use Barcode Printer

Type Laser

Style Black And White

Interface Type USB

Products Status Stock

Max. Resolution 203DPI

Color Print Speed NULL

Black Print Speed 127mm/s

Max Paper Size 104mm

Zebra GK420d Direct Thermal Label Printer

Standard Features

· Print speed: up to 5" (127 mm) per second

· Print method: direct thermal

· EPL and ZPL programming languages standard

More Standard Features

· OpenACCESS design for easy media loading

· Smallest footprint in 4-inch thermal printer

· Dual-wall reinforced plastic construction

· 32 bit RISC processor

· XML-enabled printing

Printer Specifications

Resolution: 203 dpi (8 dots/mm)
Memory: Standard: 8 MB SDRAM (3 MB available to user); 4 MB Flash (1.5 MB available to user)
Print width: 4.09" (104 mm)
Print length: 39" (991 mm)
Print speed: 5" (127 mm)/sec
Media sensors: Reflective, Transmissive

Media Characteristics

Maximum label and liner width: 4.25" (108 mm)
Minimum label and liner width: 0.75" (19 mm)
Maximum label and liner length: 0.38" (9.7 mm) to 39" (991 mm)
Maximum roll diameter: 5" (127 mm)
Core diameter: 0.5" (12.7 mm), 1.0" (25.4 mm), 1.5" (37.1 mm)
Media thickness: 0.003" (0.08 mm) to 0.0075" (0.20 mm)
Media types: black bar, black mark, continuous, continuous receipt, die-cut, fanfold, gap, notched, perforated, receipt, roll-fed, tag, tag stock

Operating Characteristics

Operating temperature DT: Operating temperature: 40° F (5° C) to 105° F (41° C)
Direct thermal Storage temperatures: -40° F (-40° C) to 140° F (60° C)
Operating humidity: 10-90% non-condensing
Storage humidity: 5-95% non-condensing
Electrical: Auto-detectable (PFC Compliant) 100-240 VAC, 50-60 Hz
Agency approvals

· FCC Part 15

· Subpart 15

· VCCI

· C-Tick

· EN55022 Class-B

· EN6100-3-2

· EN6100-3-3

· EN55024

· CCC

· CB Scheme IEC 60950: 1991 +A1 +A2 + A3 +A4

· TUV NRTL

· IRAM

· NOM

· AAMI

Physical Characteristics

Width: 6.75" (171 mm)
Height: 6" (152 mm)
Depth: 8.25" (209 mm)
Weight: 3.1 lbs (1.4 kg)
Shipping weight: 7.1 lbs (3.2 kg)
Orientation Center

Related Products

Options

· 10/100 internal Ethernet connectivity

· Dispenser - label peel and present with present sensor

· Asian font sets

Communication and Interface Capabilities

· Auto-sensing Serial RS-232 (DB-9)

· USB V1.1, bi-directional

· Centronics Parallel

· 10/100 internal Ethernet (replaces parallel port)

Programming Languages

Core programming languages: EPL2, Line Mode, ZPL I/ZPL II

Bar Codes/Symbologies

Linear Codabar
Code 11
Code 128
Code 128 with subsets A/B/C
Code 39
Code 93
EAN-13
EAN-14
EAN-8
EAN-8 and EAN-13 with 2 or 5 digit extensions
German Post Code
Industrial 2-of-5
Interleaved 2-of-5
Japanese Postnet
Logmars
MSI
MSI-3
Plessey
Postnet
RSS (reduced space symbology)
Standard 2-of-5
UCC/EAN-128
UPC and EAN 2 or 5 digit extensions
UPC-A
UPC-A and UPC-E with 2 or 5 digit extensions
UPC-A and UPC-E with EAN 2 or 5 digit extensions
UPC-E
2-dimensional Aztec
Codablock
Code 49
Data Matrix
MacroPDF417
MaxiCode
MicroPDF417
PDF417
QR Code
RSS / GS1 DataBar family (12 barcodes)
Fonts and Graphics
