Ridge Cap Roll Forming Machine
1. Ground-level land
2. ≥5T overhead travelling crane
3. Space for storing the material
4. Space for laying the machine
5. Road for vehicle moving
6. Workman: 2, operator and porter
Roof Ridge Cap Roll Forming Machine
Number Items UnitType RF-RC
1 Steel Thickness mm 0.5-0.6
2 Forming Speed m/min 8-12
3 Roller stands stand 16
4 Roller Material 45# steel, coated with chrome
5 Main Motor Power Kw 7.5
6 Hydraulic cutting Power Kw 4
7 Hydraulic pressure Mpa 10-12
8 Power Supply 380V, 50Hz, 3 phase
9 Tolerance mm 1.5
10 Material of cutting Cr12
11 Control system PLC with touch screen
12 Machine net weight T 8
